R-1020 used rotary evaporator
The Introduction
Rotating evaporating flask with large capacity and caliber has large evaporation area. It is set in the water bath to reduce pressure, spinning when heated to make the solution evaporate efficiently. It can be used in the small and pidot-scale test and production of fields like biology, pharmacy, chemical industry and foodstuff. The products can be made into system devices with multi-purpose circulating water vacuum pump, diaphragm vacuum pump, low temperature circulating pump(vacuum), circulating cooler, constant temperature circulator, low temperature cooling liquid circulating pump.
The Characteristics
1, Double sealing with Teflon (PTFE) and fluorous rubber to ensure high vacuum degree.
2,Import advanced frequency conversion control system and temperature control system from foreign countries, it’s precise and reliable.
3,Vacuum transfer valve can collect continuously without affecting system vacuum and solvent distillation.
4,Water bath electric lifting and manual lifting is mating to use easily.
5,PTFE discharge valve is corrosion resistant and non-pollution.
6,Heating kettle outside protective jacket prevent scalding.
The Technical Data of R-1020
Model |
R-1020 |
|
Ambient temperature(℃) |
5~35 |
|
Speed-regulation of main machine |
Digitaldisplay, vayiable frenquency, stepless Speed-regulation |
|
Rotary speed(rpm) |
10~130 |
|
Rotating motor (W) |
180 |
|
Evaporating capability(L/h) |
Water≥5;Alcohol≥11 |
|
Achievable vacuum(Pa) |
Below 399.9Pa |
|
Water Bath Temperature range (℃) |
Rome temp~99 |
|
Constant-temperature Resolution (℃) |
±1 |
|
Power Supply(V/Hz) |
three-phase 380/50 |
|
Heater wattage(kW) |
6 |
|
Condensing tube |
Type |
Standing, main+ auxiliary cooling and highly efficient 3 circulating coldtrap |
Condenser(m2) |
main:0.8 auxiliary:0.38 |
|
Rotary bottle (L) |
20 |
|
Rotary bottle |
20L,diameter of flange opening:Φ125mm |
|
Collecting bottle (L) |
10 |
|
Collecting bottle |
Double sealing rings made of Teflon + Vinton materials |
|
Water Bath size(mm) |
Φ450×260 |
|
Water Bath material |
Stainless water bath |
|
Water Bath volume(L) |
35 |
|
Elevating function |
Electric elevation |
|
Elevating stroke(mm) |
0~190 |
|
Dimensions (mm) |
1250L×600W×2100H(Glass component included) |
|
