Home > Electrical & Electronics > Telecommunication & Broadcasting > Fiber Optic Equipment > Honserv Chinese H1200 Series 2M Transmission Analyzers / Data Tester

Honserv Chinese H1200 Series 2M Transmission Analyzers / Data Tester

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

China

Brand Name:

HSV

Model Number:

H1200

Contact Supplier Request Quote Chat Now

Shenzhen Hontek Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Hongkong

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin China

Brand Name HSV

Model Number H1200

Specifications

2m Transmission Analyzer,2m Bert Tester,2m Data Tester , Find Complete Details about 2m Transmission Analyzer,2m Bert Tester

E1 tester 2M Transmission Analyzer E1 BER Tester 2M Data Tester

2m Transmission Analyzer,2m Bert Tester,2m Data Tester , Find Complete Details about 2m Transmission Analyzer,2m Bert Tester,2m Data Tester,2m Transmission Analyzer,2m Bert Tester,2m Data Tester from Other Telecommunications Products Supplier or Manufacturer

Technical Index:

2M Technical Index

(1) Signal input rate: 2048kbit/s±100ppm(G.703 requirement±50PPM)

(2) Signal coding: HDB3, AMI.

(3) Input balance response: Attenuation complies with the law of square root of frequency, and is within the range of 0 to 6dB at 1024 kHz.

(4) Input Impedance

(4.1) Unbalance terminating: 75Ω

Balance terminating: 120Ω.

Reflection loss >18dB within 50Hz~3100kHz.

(4.2) Unbalance bridging: >W750Ω

Balance bridging: >W1200Ω

(4.3) Unbalance monitoring: 75Ω, 26dB gain

Balance monitoring: 120Ω, 26dB gain

Reflection loss >18dB within 50Hz~3100kHz.

(5) Signal structure

(5.1) Non-frame structure

(5.2) Frame structure: PCM30, PCM31, PCM30CRC, PCM31CRC

Frame structure complies with the requirement of G. 704.

(6) Testing pattern: 26-1,29-1,211-1,215-1,220-1,223-1, and artificial code

(7) Impedance of output interface:

(7.1) Non-balance 75Ω, up to G. 703

(7.2) Balance 120Ω, up to G. 703.

(8) External clock input

(8.1) Signal form: HDB3, NRZ

(8.2) Balance terminating resistance: 120Ω

Unbalance terminating resistance: 75Ω

Balance bridging resistance: >1200Ω

Unbalance bridging resistance: >750Ω

Other Parameters:

• Power supply

(1) Special power adapter

Input: AC220V 50Hz

Output: DC 9V 1A

(2) Internal rechargeable battery

4000mAh, 6V nickel-hydrogen rechargeable battery

Working time: 8 hours

Charging: 8 hours at power-off state, and 12 hours at power-on state.

• Printer: μP40-TS(CH) Chinese character micro-printer with standard level and serial port.

• Dimension :L×W×H: 200×160×42mm

Ambient para meters:

Operation temperature: 0~40°C

Storage Temperature: -30~+70°C

Humidity: 5%~90%, non-condensing

Standard Configuration:

No.	Item	Qty
1	H1200 Series 2M Transmission Analyzers	1 set
Attached files
2	User's manual	1 pc
3	Software disc	1 pc
Attached accessories
4	75 Coaxial testing line	1 pc
5	BNC-L9 Testing line CESHIYI	2 pcs
6	RS232 serial line	1 pc
7	Special testing cable of data communication 1(V.24,RS-485,EIA-530,EIA-530A)	1 pc
8	Special testing cable of data communication 2 (RS-449,V.36)	1 pc
9	Special testing cable of data communication 3 (X.21)	1 pc
10	Special testing cable of data communication 4 (V.35)	1 pc
11	G.703 CO special testing cable (64Kb/s coaxial interface)	1 pc
12	Power adapter	1 pc
13	Data self-loop head	1 pc
14	Switch cable	1 pc
15	Handy-case	1 pc
16	Serial printing line (optional)	1 pc
