Home > Products > Power supply > Shenzhen 500w 12v 42a switching power supply factory for direct sales
Shenzhen 500w 12v 42a switching power supply factory for direct sales
USD $15 - $20
/ Piece
1000 Pieces(Min.Order)
- 1000 Piece / Pieces per Month
- Shenzhen
- T/T Credit Card
You May Like
Product Details
| Place of Origin: | Guangdong, China | Brand Name: | ILM | Model Number: | ILM-A-500W-12 |
| Output Power: | 401 - 500W | Output Type: | Single | Input Voltage: | Other, 110V-240VAC |
| Output Voltage: | 5/7.5/13.5/15/24/48VDC | Output Frequency: | 50/60HZ | Output Current: | 66.7/37/33/20.83/10.41A |
Product Description
1. 3 years warranty
2. 85~264VAC full range of input or input select by switch
3. Low cost, High operating reliability at high temperature
4. Forced air cooling by built in DC fan
5. Protections: Over-load, over-voltage, over-current, over-temperature, short circuit protections
Over-load protection: Max.150% (Fold back current limiting, recover automatically after problems removal)
Over voltage protection: Max.135% (Hiccup mode, recovers automatically after faulty problems removal)
6. LED indicator for power on
7. 100% burn-in tests (at full load)
8. Built-in cooling Fan ON-OFF control
9. Suitable for many types of LED lights, LED electronics screen, Industrial control products, instruments & equipements, safety-guard products, advertisements.
10.Life span: greater than 50000hrs
11.MTBF:greater than 250Khrs
12.Withstand voltage: I/P-O/P: 3KVAC, IP-FG:1.5KVAC, DC-FG: 500VAC
13.Working temperature: -10~60°C
| Model | ILM-12 | ILM-13.5 | ILM-15 | ILM-24 | ILM-48 |
| Rated output | 12VDC/41.7A | 13.5VDC/37.1A | 15VDC/33.3A | 24VDC/20.8A | 48VDC/10.4A |
| Rated power | 500W | 500W | 500W | 500W | 500W |
| Efficiency | 76% | 79% | 81% | 81% | 83% |
Contact Us
- Shenzhen Inloom Technology Co., Ltd.
- Contact nameAlice Yang
- Phone86-755-84728277
- AddressRm.910,Zhonglv Building,No.3023 The People of South Rd.,Luohu District,Shenzhen Shenzhen,Guangdong
