Home > Electrical & Electronics > Power Supply & Distribution > Switching Power Supply > Customized Switching Power Supply 48VDC 1200W
Customized Switching Power Supply 48VDC 1200W
US$ 70 - 80
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ILM
Model Number:
ILMSP-040
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Waterproof ,rainproof Switching LED Power Supply 60WUS$ 2 - 3.5MOQ: 1000 Pieces -
Waterproof ,rainproof Switching LED Power Supply 350WUS$ 7 - 9MOQ: 1000 Pieces
-
Single Output Switching Power Supply ,LED Power Supply 400WUS$ 5 - 15MOQ: 1 Piece
-
60W Waterproof ,rainproof Switching Power SupplyUS$ 3.5 - 5MOQ: 1 Piece
-
dc ac Power Pure Sine Wave Inverter, Inverter on Line UPS Power SupplyUS$ 200 - 220MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
ILM
Model Number
ILMSP-040
Output Power
401 - 500W
Output Type
Single
Input Voltage
Other, 110V-240VAC
Output Voltage
48VDC
Output Frequency
50/60HZ
Output Current
25A max.
Specifications
1200W adjust power supply1.Certification:UL SAA PSE FCC CE C-tick
2.48VDC 25A adjust power supply
3.size:244*144*65mm
1. 3 years warranty
2. 85~264VAC full range of input or input select by switch
3. Low cost, High operating reliability at high temperature
4. Forced air cooling by built in DC fan
5. Protections: Over-load, over-voltage, over-current, over-temperature, short circuit protections
Over-load protection: Max.150% (Fold back current limiting, recover automatically after problems removal)
Over voltage protection: Max.135% (Hiccup mode, recovers automatically after faulty problems removal)
6. LED indicator for power on
7. 100% burn-in tests (at full load)
8. Built-in cooling Fan ON-OFF control
9. Suitable for many types of LED lights, LED electronics screen, Industrial control products, instruments & equipements, safety-guard products, advertisements.
10.Life span: greater than 50000hrs
11.MTBF:greater than 250Khrs
12.Withstand voltage: I/P-O/P: 3KVAC, IP-FG:1.5KVAC, DC-FG: 500VAC
13.Working temperature: -10~60°C
| Model | ILM-1200 | ||||
| Rated output | 48VDC/25A | ||||
| Rated power | 1200W | ||||
| Efficiency | 79% | ||||
