Help CenterBlack Painted Steel Strapping
Related Products
Specifications
black painted steel strapping1.Min750Mpa
2.elongation:Min3%
3.oscillated
re:406mm...
Wound Way: Ribbon wound and Oscillated wound
Matercial: Q195, Q215, Q215B, Q235, Q235B, Q345, 20MnSi steel.
Technical Parameters:
Ordinary steel strapping
Σ B≥ 65-75kg/mm2(650-750Mpa),
Elongation: δ 5≥ 3%-5%
Ordinary steel strapping
Σ B≥ 75-85kg/mm2(750-850Mpa),
Elongation: δ 5≥ 4%-6%
High quality steel strapping
Σ B≥ 85-1000kg/mm2(8501000Mpa),
Elongation: δ 5≥ 5-8%
Specifications: (ThicknessxWidth)
BWG27X3/8", 1/2", 5/8"(0.40mmx12.7mm, 16.0mm)
BWG26X1/2", 5/8", 3/4"(0.45mmx12.7mm, 16.0mm 19.0mm)
BWG25X1/2", 5/8", 3/4"(0.50mmx12.7mm, 16.0mm, 19.0mm)
BWG24x1/2", 5/8", 3/4"(0.55mmx12.7mm. 16.0mm, 19.0mm)
BWG23x1/2", 5/8", 3/4"(0.60mmx12.7mm, 16.0mm, 19.0mm)
BWG22x3/4", 1" 5/4"(0.60mmx19.0mm, 25.4mm, 32.0mm)
BWG22x3/4", 1" 5/4"(0.70mmx19.0mm, 25.4mm, 32.0mm)
BWG21x3/4", 1" 5/4"(0.80mmx19.0mm, 25.4mm, 32.0mm)
BWG20x3/4", 1" 5/4"(0.90mmx19.0mm, 25.4mm, 32.0mm)
BWG19x3/4", 1". 5/4"(1.00mmx19.0mm, 25.4mm, 32.0mm)
Coils ID: Ribbon wound=200mm/300mm/406mm; Oscillated wound=406mm
