Home > Security & Protection > Surveillance, Control & Protection > CCTV Camera > Best Home Security System Camer Digital Cctv 3.0mp ip Camer

Best Home Security System Camer Digital Cctv 3.0mp ip Camer

US$ 60 - 95 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

PLV

Model Number:

PLV-NC401B

Contact Supplier Request Quote Chat Now

Shenzhen Power Leader Video Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name PLV

Model Number PLV-NC401B

Type Digital Camera

Style Dome Camera

Sensor CMOS

Technology Infrared

Special Features Waterproof / Weatherproof

Best home security system camer digital cctv 3.0mp ip camer

Product Description

Key Features:

4MP(2592*1520)@15fps or 3MP(2048*1536)@25/30fps
H.265/H.264 High Profile compression algorithm
2.8~12mm Manual Vari-Focal Lens
1/3” CMOS Image Sensor
Day/Night Mode Auto-Switch
ONVIF
30meters IR distance
IP66 Waterproof Metal Casing
DC 12V Power Supply

Product Pictures:

Product Details:

Why we need 3mp/4mp full hd ip camera ?

We don't just want to see it. We must watch it clearly.
So we need to upgrade the system from Standard Definition to High Definition
So we need to upgrad to H.264/H.265 High Profile compression algorithm
Best choice make things easy
PLV, Bring You a Clear World, Guard Your Happy Life

Main Parameters:

Camera
Image Device	1/3" Progressive CMOS	Shutter Time	1/25s~1/100,000s
Lens	2.8/4/6/8/12mm Manual Vari-Focal Lens	Lens Mount	CS
Day&Night	ICR	WDR	Digital WDR
Minimum Illumination	Color:0.01Lux F1.2,B&W:0.001Lux	DNR	2D/3D DNR
Auto Iris	-	POE	Optional
Video
Video Compression	H.265/H.264	H.264 Profile	High Profile
Bit Rate	Main Stream:0.1Mbps ~10Mbps Sub-stream:0.1Mbps ~4Mbps	Resolution	Main:25921520/20481536 Sub:1280720/704576
Frame Rate	50Hz:15fps(2592×1520)/25fps(2048×1536),60Hz:15fps(2592×1520)/30fps(2048×1536)
Audio(Optional)
Audio Compression	G.711	Talk Back	Support
Network
Protocols	TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, FTP, UPNP
Alarm Trigger	Motion detection, Video Analysis, Shelter	Onvif Protocol	Support
Remote Access	CMS, IE, Mobile Phone	3G Module	Extended by USB interface
WIFI	Extended by USB interface	WIFI Encryption	-
Interface
Network Interface	1 RJ45 10M/100M Ethernet Port	USB Interface	Support(Optional)
Audio In	1channel(Optional)	Audio Out	1channel(Optional)
Alarm In	2channel(Optional)	Alarm Out	-
Storage Interface	-	Serial Port	RS-485(Optional)
General
Operation Temperature	-10℃~ +60℃	Working Humidity	0% - 90%
Water-proof Casing	IP66	Adapter Requirement	DC12V±10%
Power Consumption	5.5W MAX(7.5W When IR turn on)	EXIR range	Up to 30M
Dimensions(mm)		Weight

How does ip camera POE system work?

Typical applications:

Widely applied in Banking, Super Market, Telecommunication, Government, School, Airport, Factory, Hotel, Restaurant, Bus/train Station, Public Square, Building, Store, Office, House and other fields that need HD video surveillance.

Packaging & Shipping

How is the shipping and packaging?

1.The package will be shipped from China via Express air or by sea as your request. The tracking number will E-mail to you when the item sent, usually it takes 4~5 working days to arrive by air;it takes 10~45 days to arrive by sea depending on the port.

2.For fast and safe delivery,we can not deliver to P.O. Box number .Please provide physical address and contact phone number.

Our Services

What service does PLV provide?

1.OEM/ODM Service: rint your logo and stick your model No.on the cameras,boxes,

2.One-year Wanranty.Free repair within 30 days after the shipment of the products

3. Professional 24-hours technician supports.

Customer`s satisfactory is most important to us.

If you have any problem or questions regarding our transaction.Please don't hesitate to contact us.
