construction machine wheel loader from china
Overview
"Quality Assurance" is our eternal pursuit and promise.
More details of construction machine wheel loader from china
|
936 Specification |
Dimension |
6650*2280*3000mm |
Rated Load |
2200kg |
|
Operate Weight |
6300kg |
|
Bucket width |
2400mm |
|
Max. Dumping Height |
3600mm |
|
|
Optional Accessories |
Quick-change connector, Quick-change bucket, Quick-change pallet fork Quick-change wood grasping, Quick-change grass fork Air-condition & Rearview camera |
|
|
Engine |
Model |
DEUTZ(WP6G125E22)
|
Rated Power/speed |
92kw/2400rpm(125 HP) |
|
|
Optional Engine |
CUMMINS 4BTA3.9-C125 |
|
Pattern |
Inline, Water-Cooled, 4-Stroke, Direct Injection |
|
|
Transmission System |
Gearbox Model |
300 Split type |
Axle |
20G Big hub reduction axle |
|
Drive Mode |
Four-wheel Drive |
|
Optional Accessories |
Pilot control valve |
|
|
Steering System |
Steering Angle |
±35° |
Min. Turning Radius |
5700mm |
|
Pattern |
Articulated type, full-hydraulic power steering |
|
|
Braking System |
Service Brake |
Hydraulically-actuated, wet disc brakes actuate on four wheels |
Parking Brake |
Wet, multi-disc brake on transmission output shaft |
|
Tyre |
Size |
16/70-24 |
Is there any quick attachment available?
Here it is!
Thank you for your time.
If there is anything question, please contact Joanne for further consultation.
Packaging: Nude package, whereas construction machine wheel loader from china transporting use 12mm diameter steel wire rope for lashing. 1 set in 1 x 40' HQ container.
Shipping: FOB QINGDAO China. CFR or CIF is available as well.
Shandong Outailong Heavy Industry Co.,Ltd.,a professional engineering machinery manufacturer with 11 years experience. Our core competencies is mini-medium-sized wheel loader. Hopefully to become your trustworthy loader supplier in China.
Q:Why choose AOLITE?
A:1) AOLITE: an experienced loader manufacturer with over 10 years.
2) AOLITE TEAM: customers-focused,you'll get reply within 5 minutes.
3) AOLITE loaders: premium quality with reasonable price.
4) QUALITY: CE,BV,SGS,ROPS and FOPS,ISO9001:2008 varified.
Q:What is AOLITE warranty?
A:1) AOLITE after-sales: life-long, meantime offer one year warranty.
2) AOLITE proposal: order some wearing parts with loader for easy maintenance.
Q:What about AOLITE delivery term?
A: 10-14 days after down payment received.
Q:Which continent you export to?
| Southeast Asia | Central Asia | Africa | Latin America | Europe | Oceania |
| YES | YES | YES | YES | YES | NO |
Q:What about the payment term?
A: 30% advance payment,70% balance by T/T.
| T/T | L/C | Western Union | D/A | D/P | Paypal | Money Gram |
| YES | YES | YES | YES | YES | NO | NO |
Contact Joanne for further consulation
