18650 Li-ion Battery Pack 12V 20AH for UPS / Backup Energy

FOB Price

US$ 19.99 - 80.99 / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

18650 12V 20Ah li-ion battery pack for UPS / backup energy
1.Longer life.High safety
2.Light weight
3.smaller si

No	Item ()	General Parameter	Remark
1	Rated Capaci	(Typ.) 2ah	Standard charge and Standard discharge
1	Rated Capaci		Standard charge and Standard discharge
2	Nominal Voltage	12.8V
3	End of Charge Voltage	14.6V
4	Charge mode	CC,CV
5	Charging current	≤25A
6	Charging cut-off current	0.02C
7	Charging time	≈4h
8	Over-Charge Voltage Protection(cell)	3.9V
9	Over-Charge Voltage Protection(Pack)	15.6V
10	Discharging Current	2A
11	Maximum Continuous Discharging Current	4A

Continuous the table 1

No	Item	General Parameter	Remark
12	Discharge of Peak current	________________
13	Over-disCharge Voltage(cell)	2.0V
14	Over-disCharge Voltage Protection(Pack)	8~10V
15	Over-Current Discharge Protection	15A
16	Short circuit protection	Have
17	Short circuit protection Release	_________________
18	Cell Dimension	length 95mm	Can change
		width 90mm
		height 135m
19	Weight	≈240g
20	Operation Temperature Range	Charge 0~45°C	60±25%R.H. Bare Cell
20	Operation Temperature Range	Discharge -10~60°C	60±25%R.H. Bare Cell
21	Storage Temperature Range	1 month -20°C ~ 45°C	60±25%R.H. at the shipment state
		3 month -20°C ~ 45°C
		1 year -20°C ~ 20°C

No	Item ()	General Parameter	Remark
1	Rated Capaci	(Typ.) 2ah	Standard charge and Standard discharge
1	Rated Capaci		Standard charge and Standard discharge
2	Nominal Voltage	12.8V
3	End of Charge Voltage	14.6V
4	Charge mode	CC,CV
5	Charging current	≤25A
6	Charging cut-off current	0.02C
7	Charging time	≈4h
8	Over-Charge Voltage Protection(cell)	3.9V
9	Over-Charge Voltage Protection(Pack)	15.6V
10	Discharging Current	2A
11	Maximum Continuous Discharging Current	4A

Continuous the table 1

No	Item	General Parameter	Remark
12	Discharge of Peak current	________________
13	Over-disCharge Voltage(cell)	2.0V
14	Over-disCharge Voltage Protection(Pack)	8~10V
15	Over-Current Discharge Protection	15A
16	Short circuit protection	Have
17	Short circuit protection Release	_________________
18	Cell Dimension	length 95mm	Can change
		width 90mm
		height 135m
19	Weight	≈240g
20	Operation Temperature Range	Charge 0~45°C	60±25%R.H. Bare Cell
20	Operation Temperature Range	Discharge -10~60°C	60±25%R.H. Bare Cell
21	Storage Temperature Range	1 month -20°C ~ 45°C	60±25%R.H. at the shipment state
		3 month -20°C ~ 45°C
		1 year -20°C ~ 20°C
