Help CenterSHR-1000A Hot Mixer
Related Products
CE approved mixer specially designed for the plastic high speed mixing,drying, coloring.
- high speed mixing motor inverter started
- high speed parts 3 methods temperature increatig: material self-friction/electric heating/conduction oil heating
- material discharge 2 methods: temperature controller automatic release/mixing time control
- the parts contact with raw material are all made of stainless steel 304 and mirror polishing treatment
- the barrel covers and three direct links made of cast aluminum
- the bearing chambers with special designs for the lubricating oil injection
- driving motor over current protection design
- PLC touch screen control system can be choosed for the high automatic control requirement
- special designed mixing axis design can avoiding the raw material leaking from the barrel
- mixing paddles after strict balance test
There are many different kinds of mixing types,Vertical hot/cold mixer unit;Horizontal mixing unit;Hot mixer.
SHR-1000A is only one of our hot mixer.
More types of Hot mixer as below:
| Type | Volume(L) | Effective volume(L) | Motor(KW) | Heating method | discharge | speed(rpm) |
| SHR-5A | 5 | 3 | 1.1 | self-friction | manual | 600-3000 |
| SHR-10A | 10 | 7 | 3 | Electric | manual | 600-3000 |
| SHR-50A | 50 | 35 | 7/11 | Electric | pneumatic | 750/1500 |
| SHR-100A | 100 | 75 | 14/22 | Electric | pneumatic | 650/1300 |
| SHR-200A | 200 | 150 | 30/42 | Electric | pneumatic | 475/950 |
| SHR-300A | 300 | 225 | 40/55 | Electric | pneumatic | 475/950 |
| SHR-500A | 500 | 375 | 55/75 | Electric | pneumatic | 430/860 |
| SHR-800A | 800 | 600 | 83/110 | Electric | pneumatic | 370/740 |
| SHR-1000A | 1000 | 750 | 90/132 | Electric | pneumatic | 325/650 |
| SHR-1300A | 1300 | 975 | 250 | Electric | pneumatic | 250/500 |
Vertical Hot/Cold mixing unit :
SRL-Z Model |
SRL-Z100/200 |
SRL-Z200/500 |
SRL-Z300/600 |
SRL-Z500/1000 |
SRL-Z800/1600 |
Total Volume (L) |
100/200 |
200/500 |
300/600 |
500/1000 |
800/1600 |
Effective Volume(L) |
75/150 |
150/375 |
225/450 |
375/750 |
600/1200 |
Mixing Speed(rpm) |
650/1300/200 |
475/950/130 |
475/950/100 |
430/860/70 |
370/740/50 |
Heating/Cooling Method |
Electric/self-friction/recycling water |
||||
Mixing Time(minutes) |
8-12 |
8-12 |
8-12 |
8-15 |
8-15 |
DS Driving Motor(kw) |
14/22/7.5 |
30/42/7.5 |
40/55/11 |
47/67/15 |
80/110/22 |
Inveter Driving Motor(kw) |
22/7.5 |
45/7.5 |
55/11 |
75/15 |
110/22 |
Dimension(m) |
1.95X1.6X1.8 |
4.58X2.24X2.47 |
4.8X2.64X2.48 |
5.6X3X3.1 |
5.17X3.2X4.48 |
Weight(kg) |
2200 |
3400 |
3600 |
6500 |
9800 |
Horizontal Hot/cold mixing unit :
| SRL-W model | SRLW300/1000 | SRLW500/1600 | SRLW800/2000 | SRLW1000/3000 | SRLW800*2/4000 |
| Total Volume(L) | 300/1000 |
500/1600 | 800/2000 | 1000/3000 | 800*2/4000 |
| Effective volume(L) | 225/700 | 330/1000 | 600/1500 | 700/2100 | 1200/2700 |
| Stirring speed(rpm) | 475/950/80 | 130/860/70 | 330/660/60 | 300/600/50 | 350/700/65 |
| Mixing time(min) | 8-12 | 8-12 | 8-12 | 8-12 | 8-12 |
| Power(KW) | 40/55/7.5 | 55/75/15 | 83/110/22 | 110/160/30 | 83/110*2/45 |
| Weight(KG) | 3300 | 4200 | 5500 | 6500 | 8000 |
Advantage:
- world famous brands major parts:
| Motor | SIEMENS |
Inverters |
ABB/ FUJI / LG / OMRON |
| Contactors | SIEMENS / Schneider |
| Temperature controllers | OMRON/ RKC |
| PLC system | SIEMENS/ DELTA |
- Skilled workers for machines producing
- Experience engineers all with passports ready for customers services
- Good Prices get from square quantity major parts purchase with lower cost
- Full line running test for customer checking before delivery
- Packaging: poly-wooden cases for SHR-1000A Hot mixer , no need fumigate; bubble films packaging
- We suggest the customer to purchase poly-wooden case packaging; if no, we will fixed the machines on containers walls with steel wires
- pre-sales services: we will take customers to visit our factory and check the machines quality from airport/bus station/train stations
- we will re-designed the machines according to customer's different raw material formulations: driving motors power, electric power model, wall thickness of barrel, control method
- after sales services: we will offer electric diagram, installation diagram, usage manual
- we will offer the customers online introduction to solve the machines problems/send engineers for customers machines installation, running test, workers training, machines repairmen services.
- we will offer customers spare parts at cost prices all life long of the machines
- BEIERMAN MACHINERY was established by three skilled technician/engineer/sales for plastic extruding line, plastic recycling lines producing, sale and services.
- We have 3000 square meters working house for machines making, there are 40 workers for machines producing and a 5 engineers service team for the machines running test, installation, workers training and machines repairmen.
- we have already get CE and ISO9001 corticated for our machines and factory, which ensured the high quality level of all machines we are producing
- we will attend several home and abroad plastic machines industry fairs to show the customers our quality, machines and services.
- there will be 1-2 new produced machines will be showed to the customers every year.
- we already established cooperation with the customers from Middle East, Southeast Asia and south America countries.
