Specifications
ultrasonic operating coat machine1.Model: NK-SS2012
2.Frequency: 20KHZ
ultrasonic non-woven operation coat machine(NK-SS2012)
Technical parameters of ultrasonic non-woven operation coat machine:
Product name: non-woven operation coat machine
Model: NK-SS2012
Frequency: 20KHZ
Voltage: 220V
Power: 1500W
Dimensions: 1400*700*1500MM
Weight: 80KG
Capacity: 5-15M/min
The features of ultrasonic non-woven operation coat machine:
1.No needles and thread, to save costs and avoid the trouble of breakage line;
2.human nature and ergonomic design, easy to operate;
3.Welding lines and curves can be processed;
4.Compliance with the requirements of watertight, airtight, anti-virus (bacteria);
5.floral whorl by graphic design, enhancing the strength and beauty of the processed goods;
ntrolled welding width, increase productivity;
7.The special equipment with molten arm design for better welding sleeve, which is the first device for seamless garment.
Details display:
E-box with intuitive design, more humane, the amplitude and current data are clear at a glance, easy to check. The E-box can easily to adjust the machine power, apply to many different kinds of material; you can adjust the up and down model rotate speed respectively.
The welding roller and the upper ultrasonic horn are made of special alloy steel, all kinds of welding roller design with customers' requirments;durable Taiwan original imported steel upper ultrasonic horn
Application of ultrasonic non-woven operation coat machine:
Application of industry:
dical industry: surgical clothing, caps and shoes.
2.industrial: anti-corrosion coat, electrostatic coat, strainer screen, bouffant caps.
3.automobile industry: chair cover, headrest.
4.other industry: suit cover, shower caps.
The samples of ultrasonic non-woven operation coat machine:
