Numerically Controlled Leather Punching Machine

  Dongguan City South Nekon Machinery Co.,ltd is located in Zengwu industrial area, Shipai town, Dongguan city. It is a professional manufacturer in automatic ultrasonic equipment for over 20 years .we can offer full automatic equipments for medical face mask, cup mask (bowl mask), duckbill mask, disposable mask, tridimensional mask, N95 mask, dust mask and other non-woven masks, has been provided whole production line of masks for many domestic and foreign enterprises, and got an good reputation in this industrial.

  The whole Numerically Controlled (CNC) Leather Punching Machine and it’s tools use the overall cast frame, which ensure the stable and strong of the machine, the transmission mechanism adopts the imported leading screw, the nut is flexible and accurate. Meantime, this numerically controlled (CNC) leather punching machine adopts the smart cutter controlling, the cutter can be rotate or not according to your requirement. Processing software which developed by ourselves can change the punch angle freely, different patterns can be punched according to the use of special cutters.
This Numerically Controlled(CNC) Leather Punching Machine is the seamless connection of the software technology and the CNC technology, CNC technology is the core of advanced manufacturing technology, one is moving in civilized, networked, flexible and intelligent direction.

Model No.: NK-CK153
Supply Power: 220V, 50hz/60Hz
Weight  : 500kg
Air   pressure: 5-6kg/cm2
Dimension : 2000 x 2000 x 1500 mm
Working area: 1280 x 790mm
Dia of punching holes: 0.5 ~0.8 mm
Tolerance: 0.1 mm

1. After start the machine, it will work automatically, after finished the processing the punchers will back-situ itself, this machine is efficiency and safe.
2. With one cutter you can punch multi patterns, and you can simulate the punching in the computer.
3. Can punch in any position on the products, flexible and smart.
4. Suitable for the punching of small size and complicated patterns on products which right solve the problem of production of the small molds.
5. To rise the production efficiency, South Nekon Numerically Controlled Leather Punching Machine adopts two sets of linkage device, then the machine can work in two separately area at the same time. The standard working size of the machine is 1280 x 790mm,but we can make special working area according to customers requirements.
6. Nekon Numerically Controlled Leather Punching Machine is suitable for the punching of many kinds of material: plastic, PU, EVA, PVC, fabric, paper, shoes upper, car seats and so on.
7. Diameter of the holes/punching: 0.5~6mm,
8. With quality punching effect, without destroy the material, won’t burn the material or make it yellow or black. This leather punching machine take the pneumatic impact force as it’s motive power, then use many cutters in many types, after punching, the surface will be still in flat, compared with the laser machine, won’t be burnt to be hard or black.
9. The design and change of punching pattern will control by the software and the cutters, without changing of other mechanical spare parts.
10. Supply Power:Frequency: AC 50/60Hz Voltage: 220~240V And machine must be earthing safely.

Applications of Numerically Controlled Leather Punching Machine (Leather Perforating Machine):

  This leather punching machine is suitable for the punching processing of leather, sheep skin and cow hide, artificial leather, PU, EVA, PVC, all kinds of fabric, papers, leather decorations, leather ornaments, curtains, and the car seats leather etc. Can be used for industries as spares of automobile(the breathable cushion), luggage and hand bags, stationary, shoes, breathable material, advertising paper etc. This numerically controlled leather punching machine also known as bag punching machine, leather punching machine, shoes upper punching machine, shoe material punching machine, car/automobile seats punching machine, bags and suitcase punching machine, computer leather punching machine, auto leather punching machine, intelligent leather punching machine etc.

plywood or wooden case

we provide one year warranty and technical support

engineers available to service machinery oversea

Q:1.

A: Are you a factory or trading company?

B: We are s factory with license of import &export

Q:2.

A: can i put my LOGO/brand on the machine and finish products?

B: We are s factory with license of import &export

Q:3.

A:  do you have after sale service?

B: yes. we provide one year warranty and technical support

Q:4.

A:  How can we know the quality of your machine?

B:   You can send material to us and then we use our machine to manufacture finished products which will be re-sent to you. And you are welcome to visit our factory to check quality of our machines.
