Help CenterPlastic Crusher PC1200
Related Products
CE/SGS approved Crusher for plastic, for soft and rigid plastic,
The Crusher adopts imported high-quality tool steel,special cutting-tool. It is specially durable.
The installation of the cutting tool can be adjusted. The cutting tool can be sharpened again. Its life is long.
The rotary cutting knife stand is a step designing to make cutting force resolve and increase the cutting force times.
The material of the rotary cutting knife stand,its hardness and softness is reasonable. It is not easily broken or worn. It adopts high-strength steel screw to fix it. The structure is firm and durable.
There are many different type Crusher ,for different special plastic,with different capacity.
Here I offer is only one of our Plastic Crusher PC1200,
The PC-1200 can be used to crush both bottle and film,only need 1 crusher is OK for bottle and film.
If customer need 2 different crushers, specially designed for bottle, specially designed for film,
That is also OK.
There will be little difference of structure between bottle crusher and film crusher.
Bottle crusher includes Electric press device;
Film crusher excludes presser device.
| Type | PC1200 |
| Motor power | 75KW |
| Aperture diameter of screen | 45mm |
| Rotary cutter | 12pcs |
| Stationary cutter | 6pcs |
| Blades material | SKD-11 |
| Crush bottle ability | 500-800kg/h |
| Machine Dimension | 2.5m*2.1m*2.55m |
| Machine weight | 4500kg |
Advantage:
- world famous brands major parts:
| Motor | with SIEMENS |
Inverters |
with ABB/ FUJI / LG / OMRON |
| Contactors | with SIEMENS / Schneider |
| Temperature controllers | with OMRON/ RKC |
| PLC system | with SIEMENS/ DELTA |
- Skilled workers for machines producing
- Experience engineers all with passports ready for customers services
- Good Prices get from square quantity major parts purchase with lower cost
- Full line running test for customer checking before delivery
- Packaging: poly-wooden cases for PC1200 Crusher, no need fumigate; films packaging
- We suggest the customer to purchase poly-wooden case packaging; if no, we will fixed the machines on containers walls with steel wires
- pre-sales services: we will take customers to visit our factory and check the machines quality from airport/bus station/train stations
- we will re-designed the machines according to customer's different raw material formulations: driving motors power, electric power model, wall thickness of barrel, control method
- after sales services: we will offer electric diagram, installation diagram, usage manual
- we will offer the customers online introduction to solve the machines problems/send engineers for customers machines installation, running test, workers training, machines repairmen services.
- we will offer customers spare parts at cost prices all life long of the machines
- BEIERMAN MACHINERY was established by three skilled technician/engineer/sales for plastic extruding line, plastic recycling lines producing, sale and services.
- We have 3000 square meters working house for machines making, there are 40 workers for machines producing and a 5 engineers service team for the machines running test, installation, workers training and machines repairmen.
- we have already get CE and ISO9001 certificated for our machines and factory, which ensured the high quality level of all machines we are producing
- we will attend several home and abroad plastic machines industry fairs to show the customers our quality, machines and services.
- there will be 1-2 new produced machines will be showed to the customers every year.
- we already established cooperation with the customers from Middle East, Southeast Asia and south America countries.
More crushers as below:
Model |
SWP-320 | SWP-400 | SWP-500 |
SWP-600 |
SWP-800 |
SWP-1000 |
SWP-1200 |
Power(kw) |
5.5 | 15 | 22 |
22 |
37 |
45/55 |
75/90 |
Rotation blades quantity (pcs) |
3 | 12 | 6 |
8 |
10 |
10 |
10 |
Fix blades quantity (pcs) |
2 | 2 | 2 |
2 |
4 |
4 |
4/6 |
Blade material |
9CrSi |
Cr12MoV, alloy steel |
9CrSi |
SKD-11 |
SKD-11 |
SKD-11 |
SKD-11 |
PC series plastic crusher machine technology information:
Model |
PC -400 |
PC -500 |
PC -600 |
PC -800 |
PC-1000 |
PC-1200 |
Power(kw) |
7.5 |
15 |
22 |
30 |
55 |
75 |
Rotor blades quantity(pcs) |
3 |
6 |
6 |
6 |
6 |
6 |
Fixed blades quantity(pcs) |
2 |
2 |
2 |
2 |
4 |
4 |
Blade material |
SKD-11 |
SKD-11 |
SKD-11 |
SKD-11 |
SKD-II |
SKD-II |
