Specifications
1.Card material:PVC,PET,ABS2.Card size:85.5*54*0.76MM(standard)
3.High quality printing scraping card printing both side
1)High quality printing scraping card material: PVC, PET, ABS
2)Card size: 85.5*54*0.76MM (standard), or according to your request.
3)Thickness:ISO standard 0.76MM,0.6MM,0.5MM,0.3MM
4)Printing Method: Four colors offset printing, silk-screen printing
5)Other available option: magnetic strip,barcode,embossing number, signature panel, Pin number, serial number, scratch strip,hot-stamping,chips,etc
6)Chip available: Philips Misfire 1K S50,S70,SLE4442,SLE4428,SLF5528,Simens ceries,Temic series,AT24C16,AT24C64,AT series,FuDan Series,EM4100,TK4100,etc
7)Packaging: 250pcs/box, 20boxes/caton, box size: 22.5*9.3*6cm, carton size: 13*23.5*50cm
8)Weighty: 1000pcs 5.4KG, 5000pcs 27KG
7)Printing:Glossy 4/4 color offset printing both side,also can do silk screen, panton color printing.
8)Craft: Printing both side with barcode strip on the back.
The barcode available are 128 code,13 code,39 code etc.
9)Chip style: We offer ID thick card like T5557, ID thin card like EM4100 etc.
10)Available crafts: magnetic strip, scratch off strip,signature panel,
serial number(thermal ,inkjet and embossing Nos), hot-stamping, laser/hologram.
11)We accept custom material and artwork/design order
Contact IC Chip model | ||
Factory |
Model number |
Specification |
Siemens |
SLE5542(4442) |
256bit encryption card,can read data,write data and password,protect data and write password. |
ISO 7816 Compliant pad locations | ||
256*8 bit EEPROM organization | ||
byte-wise addressing | ||
Irreversible byte-wise write protection of lowest 32 addresses (byte 0-31) | ||
32*1 bit organization of protection memory | ||
2-wire link protocol | ||
Answer to reset according to ISO standard 7816-3 | ||
Programming time 2.5mS per byte for both erasing and writing | ||
Minimum of 10000 write/erase cycles | ||
Data retention > 10 years | ||
Programmable Security Code (PSC) | ||
Data write only after correct 3-byte PSC | ||
SLE5528(4428) |
ISO 7816 Compliant pad locations |
|
1024*8 bit EEPROM organization | ||
byte-wise addressing | ||
Irreversible byte-wise write protection of lowest 32 addresses (byte 0-31) | ||
32*1 bit organization of protection memory | ||
2-wire link protocol | ||
Answer to reset according to ISO standard 7816-3 | ||
Programming time 2.5mS per byte for both erasing and writing | ||
Minimum of 10000 write/erase cycles | ||
Data retention > 10 years | ||
Programmable Security Code (PSC) | ||
Data write only after correct 3-byte PSC | ||
Shanghai Fudan |
FM4442 |
256bit encryption card,can read data,write data and password,protect data and write password.(compatible SLE4442) |
FM24C16 |
16Kbit |
|
FM4428 |
1024bit encryption card,can read data,write data and password,protect data and password operation.(compatible SLE4428) |
|
Shanghai Beiling |
BL7442 |
256bit |
BL24C04 |
4Kbit |
|
ISSI |
ISSI4442 |
256bit |
ISSI24C16 |
16Kbit |
|
ISSI4428 |
8Kbit |
|
ATMEL |
AT24C01 |
1Kbit(stop production) |
AT24C02 |
2Kbit |
|
AT24C04 |
4Kbit |
|
AT24C16 |
16Kbit |
|
AT88SC102 |
1Kbit |
|
