X-ray Inspection Machine manufacturer for PCB
- 100 Set / Sets per Month
- shenzhen
Product Details
Place of Origin: | Guangdong, China | Brand Name: | XRAY | Model Number: | JAGUAR 3500 |
Power: | Electronic | Usage: | Auto Testing Machine |
Product Description
X-ray Inspection Machine manufacturer for PCB
The X-ray inspection machine XG5010 is widely used in lithium battery, SMT, LED, electronic products processing and casting manufactures. It mainly analyses internal defects of product with images in high quality, high magnification and high resolution.
Characteristics
(1)Automatic detection
Automatic detection alignment of negative and positive of battery, and statistics the maximum/minimum values at the same time.
(2)Automatic judgment
Automatic make a judgement of NG/OK products according to the setting standard.
(3)Convenient and quickly
The machine is with accurately position, quick and convenient to user.
(4) Safety protection
Doors are equipped with photoelectric sensor. The machine will immediately stop and get into a protection model if any door is open.
Specification:
model | JAGUAR-3500 (X-ray 100KV) |
Display | 22" LCD monitor |
Image area | 600*415 mm |
Image Resolution | 110 LP/CM |
CCD Pixel | 1.3 million |
Camera Spec | Image Intensifier+Digital CCD 25 frames/m |
Magnification | 120(Geometric )/1200(System) |
X-ray Output Voltage | 90 ~ 130 KV |
Field of view | 0 ~ 70℃ tilt, 360℃ rotate |
Focal Spot | 5 um |
X-Ray Tube Type | Closed tube |
Power Supply | Single phase AC 110~230V/50~60HZ |
Weight | 1100KG |
Testable Weight | sample <5 KG |
Work Table | X / Y / Z / Q Axis |
Manual Operation | by keyboard/mouse/navigation positioning |
CPU | Intel Pentium |
Memory | 2GB |
Computer System | Win7 |
Input | Keyboard |
Report Output | Manual/auto save tested doc |
video Function | Standard |
Dimension | 1160*1090*1857 mm |
Navigation | Automatic scanning navigation |
3D View | Imitation |
Void, BGA, Distance Inspection | Auto-inspect function settable |
BGA Auto Inspection | set the counting of BGA inspection,measurement and bubble |
Inspection Area | X / Y plane direction |
Special Isolation | Non |
Temperature Humidity | 0-40℃ 0-90% |
Suspended matter | non-conductivity dust |
