Home > Products > Insulation Bricks > Fire brick prices for Diatomite insulation Brick
Fire brick prices for Diatomite insulation Brick
- 5000 Ton / Tons per Month
- Tianjin/Shanghai/Qingdao
- T/T
You May Like
-
fire brick mullite insulation brick for oil furnace
-
for glass furnace JM28 mullite insulation refractory brick
-
used for glass furnace mullite insulating refractory brick
-
for glass kiln Hot Sales fire brick JM23 mullite insulation brick
-
for glass furnace refractory brick JM32 mullite insulation brick
-
mullite insulation refractory brick JM23 for glass furnace
Product Details
| Place of Origin | Henan, China | Shape | Brick | |
| Material | Diatomite | SiO2 Content (%) | 70-71.5 | |
| Al2O3 Content (%) | 16.5-18 | |||
| Model Number | GG-0.5,GG-0.6,GG-0.7,GG-0.8,GG-1.0 | Brand Name | Sunrise |
Product Description
Specifications
1.Light weight2.high strength
3.ISO9001:2008
Diatomite insulating bricks
Material and Technical
This diatomite insulating bricks are made of high diatomite, bonding with other porous materials. Produced by our licensed technology, shaping by casting, sintering at high temperature then cutting and polishing to the demand sizes, the strength and insulating property are obviously improved.
Application
Diatomite insulating bricks can be used in reduction cell and hot blast pipe of various thermal equipments, which placed in the high requirement on heat-insulating.
A-Standard of our supply
B-Standard of GB
C-Standard of industry
Diatomite Insulation Brick
physical and chemical index
Sunrise Brand | GG-0.5 | GG-0. 6 | GG-0. 7 | GG-0.8 | GG-1.0 |
Max Service Temperature (°C) | 900 | 900 | 900 | 900 | 900 |
Bulk Density (g/cm3) ≤ | 0.5 | 0.6 | 0.7 | 0.8 | 1.0 |
Cold Crushing Strength (Mpa) ≥ | 0.8 | 1.2 | 2.0 | 3.5 | 5.0 |
Reheating Linear Change (%) 900 °CX 8Hr ≤ | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 |
Thermal conductivity(W/m.k) 300°C | 0.11 | 0.15 | 0.18 | 0.20 | 0.23 |
SiO2 (%) | 71.5 | 71.0 | 70.5 | 70.0 | 70.0 |
Al2O3 (%) | 16.5 | 17.0 | 17.5 | 18.0 | 18.0 |
Fe2O3 (%) | 4.0 | 4.2 | 4.5 | 5.0 | 5.0 |
