Help CenterBamboo Stick Machinery/bamboo Stick Machine for Incence Stick/bamboo Sticks Machine Production Line
Related Products
-
Bamboo Stick Machinery/bamboo Stick Machine for Incence StickUS$ 2,000 - 9,000MOQ: 1 Set -
Automatic Bamboo Incense Stick Machine/bamboo Stick Machine for Incence StickUS$ 2,000 - 9,000MOQ: 1 Set
-
Automatic Bamboo Incense Stick Machine/bamboo Sticks Machine/bamboo Stick Making MachineUS$ 2,000 - 9,000MOQ: 1 Set
-
Automatic Bamboo Sticking Machine/bamboo Sticks Machine/bamboo Stick Making MachineUS$ 2,000 - 9,000MOQ: 1 Set
-
Bamboo Stick Cutting Machine/bamboo Sticks Machine/bamboo Stick Making MachineUS$ 2,000 - 9,000MOQ: 1 Set
Specifications
bamboo sticks machine production line1Capacity:225KG/Day
2Power:32.92KW
3Voltage:Customized
4.Products:Bamboo sticks
Bamboo sticks production/ round bamboo sticks production line/ bamboo sticks machine production line
Application of bamboo sticks machine production line
we can supply you the full lines to make wooden toothpick,bamboo toothpick,wooden skewer,bamboo skewer,bamboo incense sticks.Features of chopstick making machine:
Production process of bamboo sticks machine production line
The original bamboo sawing machine → 4m single head bamboo cutting machine → Fixed width lamination machine → 1.5 set of lamination machine → 4 axis bamboo wiredrawing machine → Bamboo stick fine cutting machine → Barbecue stick hold light machine → Simple type multi-purpose knife grinder
Specifications of bamboo sticks machine production line
The original bamboo sawing machine of bamboo sticks machine production line
Motor power:2.2kw
Blade Diameter:φ400mm
Saw shaft speed:3200r/min
Net weight:50kg
Gross Weight:85Kg
Dimension:900*440*1450mm
4m single head bamboo cutting machine of bamboo sticks machine production line
Motor power:5.5kw
Distance between Bump head and Cutter:3000mm
Largest length of bamboo:2750mm
Daily Capacity:30000 pounds of bamboo
Reciprocating times per minute:12 times/min
Net Weight:620KG
Gross Weight:750KG
Dimension:4250*900*110
Fixed width lamination machine of bamboo sticks machine production line
Power:10.6kw
Cutter diameter:φ80
Install knife number:2
Feeding speed:75m/min
Main shaft speed:3500r/min
Processing thickness:2~40mm
Processing width:15~30mm
Net Weight:580kg
Gross Weight:700kg
1.5 set of lamination machine of bamboo sticks machine production line
Motor power:1.5kw
Feeding speed:80m/min
Net Weight :80kg
Gross Weight:110kg
Dimension:520*530*1000mm
4 axis bamboo wiredrawing machine of bamboo sticks machine production line
Motor power: 9.5kw
Feeding speed:55~75m/min
Spindle speed :3500r/min
Daily capacity:1500kg bamboo
Install knife number:4
Net Weight :650kg
Gross Weight:720kg
Dimension:1270*900*940mm
Bamboo chopstick fine cutting machine of bamboo sticks machine production line
Motor power:1.1kw
Blade Diameter:φ300
Saw speed:3200 r/min
Saw blade number:1
Install knife number:4
Dimension:990*620*780mm
Chopstick hold light machine of bamboo sticks machine production line
Motor power:1.5kw
Vibrational frequency:110 times/min
Volume:0.3M³
Dimension:2400*890*760mm
Simple type multi-purpose knife grinder of bamboo sticks machine production line
Motor power: 0.55kw
Spindle speed:2800r/min
Alloy wheel diameter:φ160
Cutter diameter:φ80~φ160
Net Weight :60kg
Gross Weight:80kg
Dimension:450*350*660mm
Bamboo sticks images of bamboo sticks machine production line
Factory images and customers of bamboo sticks machine production line
Contacts of bamboo sticks machine production line
