Help Center33KV Outdoor Composite Housing LIGHTNING SURGE ARRESTER
Related Products
-
11KV Builiding Lightning Surge Arrester 5kaNegotiableMOQ: 100 Pieces -
10KV Combination Connection Type Surge Lightning Arrester for Overvoltage ProtectionNegotiableMOQ: 100 Pieces
-
Electrical Surge Arrester With Polymer HousingNegotiableMOQ: 100 Pieces
-
10kv ZnO Lightning Surge Arrester Without Gaps Export TypeNegotiableMOQ: 100 Pieces
-
Combination Type Anti-explosion High Voltage Surge Lightning ArresterNegotiableMOQ: 100 Pieces
Specifications
with mounting bracket and disconnectorWhen failure happens, it automatically disconnect to prevent further damage to arrester.
The above is the technicial parameter
Main Principle:
The Zinc Oxide Surge arrester is the most advanced over-voltage protector in the world. This is due to the incorporation of a zinc oxide arrester as the core resistor disc.
This allows an improvement in the volt-ampere characteristics of the resistor disc and an increase in through-current capability in over-voltage situations, which is a drastic improvement when compared to conventional silicon carbide arresters. Under normal operating voltage, the current through the arrester is only one micro-ampere degree. When the arrester experiences an over-voltage situation, the excellent non linear characteristics will increase the current through the arrester several thousand times. The arrester is in the conducting state and will release the over-voltage energy to earth and thereby protecting power transmission equipment against the effects of over-voltage.
Technical Performance:
Typical types of 0.22KV to 220KV polymer housed metal oxide surge arrester (YH series) is in accordance with national standard technical requirement of GB11032-2000 (IEC60099-4, T8952-2005, IEEE.C62.11) |
3~220KV lightning surge arrester
Normal service conditions:
1.The ambient air temperarture is not higher than +40 degree. not lower than -40 degree.
2.The altitude above sea level does not exceed 2000m
3.Power frequency 48Hz~62Hz
4.Maximum wind speed does not exceed 35m/s
5.The earthquake intensity does not exceed 7 degrees
6.The voltage that long-time exerted shouln't exceed its Max MCOV
