Power Cord Strain and Twist Testing Machine
US$ 1,000 - 3,000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
AUTOSTRONG
Model Number:
AUTO-10B
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
ISO6941 BS5438:1989 Textile Lab Equipment for Textile Material Burning TestUS$ 800 - 1,500MOQ: 1 Set -
IEC60950-1 Steel Ball Dropping Tester for Mobile Phone Eyeglass Impact TestUS$ 3,000 - 4,500MOQ: 1 Set
-
AC 5kv Hipot Tester With Digital Display for Laboratory EquipmentUS$ 800 - 2,000MOQ: 1 Set
-
Lab Test Equipment IEC60884-1 Lead Line Maintain Force TesterUS$ 800 - 1,500MOQ: 1 Set
-
IEC60695 Hot Wire Testing Machine Ignitability Test ChamberUS$ 3,200 - 3,800MOQ: 1 Set
Place of Origin
Guangdong, China
Brand Name
AUTOSTRONG
Model Number
AUTO-10B
Power
Electronic
Usage
Other, cable testing machine, Power Cord Strain and Twist Test
Product Description
Power Cord Strain and twist testing machine
To determine the strain and twisting of the supply cord where it enters the appliance, in accordance with IEC60335-1 clause 25.15.
Appliances provided with a supply cord, and appliances intended to be permanently connected to fixed wiring by a flexible cord, shall have a cord anchorage. The cord anchorage shall relieve conductors from strain, including twisting, at the terminals and protect the insulation of the conductors from abrasion.
A mark is made on the cord while it is subjected to the pull force shown in follow table, at a distance of approximately 20 mm from the cord anchorage or other suitable point.
The cord is then pulled, without jerking, for 1 s in the most unfavourable direction with the force specified. The test is carried out 25 times.
The cord, unless on an automatic cord reel, is then subjected to a torque that is applied as close as possible to the appliance. The torque is specified in following table and is applied for 1 min.
During the tests, the cord shall not be damaged and shall show no appreciable strain at the terminals. The pull force is reapplied and the cord shall not be longitudinally displaced by more than 2 mm.
Standard Outfit:
1 set of torque weights, 2N-5N-7N, for torques 0, 1Nm-0, 25Nm-0, 35Nm,
1 set of pull weights, 20N*2-30N*2, for strain 30 N-60 N-100 N,
1 speed fixed system, 1 times/s tension frequency,
1 control unit with 4 digit predetermining counter to switch off the drive, and records the number of tension times and torque time,
Power Supply: A. C. 220V 50Hz, other voltages and frequencies on request.
Our Advantages:
1. 1 year warranty
2. ISO17025 is free offered
3. ILAC and CNAS can be offered if required
4. ISO9001, CE , ROHS, SGS certification
5. For machines , we can offer video for customer reference
Company Information
AUTOSTRONG is one of leading enterprises in Hong Kong specialized in the R&D and manufacture of testing instruments, with more than 60 researchers from foreign countries, Hong Kong and Mainland China.
AUTOSTRONG supplies standard or customized solutions and products for many tests, measurements and quality control tasks required in the field of cable, wire, socket, plug, switch, plastic and rubber testing.All of our products are complying with the requirements of many standards, such as IEC, UL, VDE, VS, JIS, GB and so on.
