2.4GHz Digital Wireless Baby Monitor ECO-601

2.4GHz Digital Wireless Baby Monitor ECO-601 thumbnail-1
2.4GHz Digital Wireless Baby Monitor ECO-601 photo-1
US$ 80 - 88 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ECO
Model Number:
ECO-601
Contact Supplier Request Quote Chat Now
Shenzhen Eco Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Hongkong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name ECO
Model Number ECO-601
LCD Size 2.5 inch

2.4GHz Baby Monitor 601LD

>Remote Pan & Tilt control
>2.5" LCD screen with 480 × 234 resolutions
>Small palm size of receiver for mobile usage
>Built-in 9 IR lights for 5m night vision range
>3-channel available to avoid possible interference
>Channel scan and channel skip for multi-camera usage
>Min. 100m transmission distance without blocks





                                       Item

                                   Value

  Transmission Frequency

 ISM 2,400MHz~ 2,483MHz    4CH

  Modulation Mode

  FM

  Antenna Type

  Omni

  Unobstructed Effective Range

  100m(Without Block)

  Operating Temperature

  0°C~ +50°C / +32°F~ +122°F

  Storage Temperature

  -20°C ~ +60°C / -4°F ~ +140°F

  Operating Humidity

  85%RH

  CAMERA

  Imaging Sensor Type

  CMOS

  CMOS Total Pixels

  628×582(PAL)/ 510×492(NTSC)

  Horizontal Resolution

  380 TV Lines

  View Angle

  62°

  Minimum Illumination

  5Lux/F1.2 & 0Lux(IR ON)

  Transmission Power

  10mW / CE;2mW / FCC

  Power Supply

  DC 9V 1.5A

  pan Angel

  ±90°

  Tilt Angel

  ±30°

  Motor Running Life

 3000h

  Max. Load of Motor

  500g

  Dimensions

  71×73×44 mm

  Night Vision Range

  5m

  RECEIVER

  Receiving Sensitivity

  ≤-85dBm

  LCD Type

  TFT

  LCD Screen Size

  2.5"

  Resolution

  480×234

  Active Area

 49.2mm×38.142mm

  Dot Pitch

  0.1025mm×0.163mm

  View Angle(U/D/L/R)

  10°/ 30°/ 45°/ 45°(Min.)

  Brightness

  250 cd/m3

  Contrast Ratio

  '150:1

  Interface

  Alternated Video Signal

  Light Source

  CCFL*

  Power Supply

  DC 9V 1.5A

  Consumption Current

  320mA

  Vided Output level

 1Vp-p@75ohm

  Audio Output level

  1Vp-p@600ohm

  Dimensions(W×L×H)

  105×69×28 mm



 2.4GHz digital wireless baby monitor ECO-6012.4GHz digital wireless baby monitor ECO-6012.4GHz digital wireless baby monitor ECO-6012.4GHz digital wireless baby monitor ECO-601
