universal testing machine Application:
Autostrong tensile compression bend universal testing machine use servo motor and servo speed control system, advanced chip integration technology and professsional design date acquisition magnify and process control systems. This machine can apply to all kinds of metal and non-metallic materials of the metal and non-metallic materials of the mechanical ength, tensile strength, elongation of the sample, area reduction and other routine date, it also can automatically tensile strength, elongation of the sample, area reduction and other routine data, it also can automatically control system test process control and data processing in line with the corresponding metal materials and non-metallic materials national standard requirement.
universal testing machine Software Function:
Autostrong tensile compression bend universal testing machine can conduct tensile, compression,
bending, shearing, tearing and peeling test; use PC and interface board for data collection, preservation, processing and printing test result; can calculate max force, yield strength, average peeling force, max deformation, yield point, elastic modulus and other parameters.
Can conduct curve graphics processing, multi-sensor support, video and image interface, flexible data processing, MS-ACCESS database support, making more powerful function of system.
universal testing machine Main technical parameters:
Model |
AUTO3000 |
AUTO5000 |
|||||||||||||
Specification |
3103 |
3203 |
3503 |
3104 |
3204 |
5504 |
5105 |
5205 |
5305 |
5500 |
5605 |
||||
Max test force |
1KN |
2KN |
5KN |
10KN |
20KN |
50KN |
100KN |
200KN |
300KN |
500KN |
600KN |
||||
Accurate grade |
0.5 grade |
||||||||||||||
Effective measuring range |
0.4%~100%FS Inside and outside, regardless of file |
||||||||||||||
The relative error of test force value |
Within±0.5% |
||||||||||||||
Test force resolution |
1/300000 Solution unchanging |
||||||||||||||
Deformation measurement range |
0.2%~100%FS Inside and outside, regardless of file |
||||||||||||||
The relative error of displacement value |
Within±0.5% |
||||||||||||||
Displacement resolution |
1/300000 |
||||||||||||||
The adjusted range of test speed |
Within±0.2% |
||||||||||||||
The relative error of speed value |
0.001mm |
||||||||||||||
Uniform test force rate control range |
0.005~500mm/min |
0.0025~250mm/min |
|||||||||||||
Uniform test force rate control error |
Within±0.5% |
||||||||||||||
Uniform deformation rate control range |
0.01%~10%FS |
||||||||||||||
Uniform deformation rate control error |
<0.05%FS Within±0.2%; ≥0.05%FS Within±0.1% |
||||||||||||||
Control range |
0.5%~100%FS |
||||||||||||||
Control range control accuracy |
≤10%FS Within±1%; ≥10%FS Within±0.1% |
||||||||||||||
The max travel of moving crossbeam |
1100mm |
1200mm |
|||||||||||||
Effective test width |
410mm |
510mm |
570mm |
600mm |
|||||||||||
Machine size |
L75×W55×H160CM |
L90×W57×H201CM |
L110×W61.4×H220CM |
L120×W76×H250CM(200KN) L132×W79×H260CM(500KN) |
|||||||||||
Power supply |
220V/50Hz,500W |
220V/50Hz,500W |
220V/50Hz,500W |
380V/50Hz,2KW |
380V/50Hz,4KW |
||||||||||
Machine weight |
260Kg |
|
800Kg |
2000Kg |
|||||||||||
