SBS Modified Bituminous Waterproofing Membrane Underlayment

SBS Modified Bituminous Waterproofing Membrane Underlayment photo-1
SBS Modified Bituminous Waterproofing Membrane Underlayment photo-2
US$ 2 - 5.5 MOQ: 100 Square Meters
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
CNPW
Model Number:
JH-N100
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen/Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name CNPW
Model Number JH-N100
Product Description

JH-N100 SBS Modified Bituminous Waterproofing Membrane is a kind of macro-molecule material produced by advanced equipment and technology, using high-quality bitumen as its main component, Styrene-Butadiene-Styrene(SBS) as the modifier, superior materials as its reinforcement and many excellent materials as its isolating materials.

Product Feature

Low temperature resistance, high elongation ability, strong tensile strength, good abrasive resistance and easy to pave.

Scope of Application

1. Industrial and civil roofing construction such as insulation roofs, planted roofs, roof parking lots and inverted roofs, etc.

2. Industrial and civil underground construction, indoor swimming pools, fire reservoirs, etc.

3. Tunnels, subways, concrete bridges, sewage plants and refuse landfills, etc.

4. Water conservancy facilities such as pools and water channels, etc.

Technical Data

Performance Standard GB 18242-2008

                           Item                               Index
                Ι          ΙΙ
       PY        G  PY     G PYG
Content of Soluble Substance (G/m2)           3mm                               2100
          4mm                           2900
          5mm                           3500
Heat Resistant         ºC              90              105
         ≤mm                                  2
Low Temperature Flexibility/ºC             -20              -25
                           No Crack
Water Impermeability (30min) 0.3MPa 0.2MPa              0.3MPa
Tension

Maximum

Tension (N/50mm) ≥

   500   350    800   500 900
Secondly Maximum Tension (N/50mm) ≥     800
Elongation RateMaximum Elongation Rate / % ≥  30    40
Maximum Elongation Rate / % ≥       15
Increased Quality After Immersion % ≤RE/S              1.0
M              2.0



Application

1, Torch-applied method and cold adhesion method are both feasible , or we can use these two methods together during the construction, which means cold adhesion method used at the main part and torch-applied method used at the seam.

2, Torch-applied method: use spray guns or blowtorches to heat the membrane and the base surface. While the bitumen on membranes is melting, roll the membrane forward, then use roller to make the membranes and the base surface stick together.

3Cold adhesion method: brush adhesives on the base surface and membranes, after a while, pave the membranes, meanwhile press out the air with the roller until the membranes and the base surface stick together tightly and flat-wise.





SBS modified bituminous waterproofing membrane underlayment



SBS modified bituminous waterproofing membrane underlayment



SBS modified bituminous waterproofing membrane underlayment



SBS modified bituminous waterproofing membrane underlayment
