Non-asphalt Polymer Waterproofing Membrane Underlayment

Non-asphalt Polymer Waterproofing Membrane Underlayment photo-1
US$ 4 - 6 MOQ: 40 Square Meters
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
CNPW
Model Number:
JH-P200
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen/Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name CNPW
Model Number JH-P200
Product Description

JH-P200 Non-asphalt Polymer Waterproofing Membrane is a kind of multi-layer material consisting of three layers which are the bottom layer of HDPE film, the layer of powerful adhesive film, and the layer of reaction sand.

Product Feature

1, It can have a chemical reaction with concrete which can produce a high adhesive ability to effectively prevent water seepage.

2, Concrete with steel bars can be put on top after simple treatment.

3, It has good root resistant property.

4, It can be constructed on the wet substrate.

5, It has good abrasive ability and can be used for a long time

Scope of Application

Suitable for basements, subways, tunnels, swimming pools, slopping and flat roofs. The high-requirement and special environment needed waterproof such as planted roofs, underground gass in order to prevent leakage, etc.

Technical Data

Performance Standard: GB/T23457-2009 Type B

                   Item          Index (Wet-Laid Type P) Index (Pre-Laid Type P)
           Ι           ΙΙ
 Tensile Strenthtension (N/50mm) ≥          150          200               500
the maximum tensile rate % ≥          30          150               400
Tear Strength /N≥           12           25                 -
Heat Resistance 70℃(no slipping, no dripping and no fall-off)
Tear Resistance (Nail Method)/N≥             -             -               400
Low temperature flexibility /℃         -15           -25                 -
                  No cracks                 -
Folding ability at low temperature /℃                       -         -25, no crack
Fluid-channeling prevention 0.6Mpa no fluid-channeling
Water immpermeability 0.3Mpa 120min immpermeability

                   -





Company Introduction

China National Petroleum Waterproofing Technology (Shenzhen) Co., Ltd (abbreviated as CNPW), was founded in Shenzhen with its headquarter in Nansha Free Zone, Guangzhou, China and branches all of the world. The excellent management and continous R&D investment help CNPW become a  top company in waterproofing industry



CNPW is a leading waterproof membranes and waterproofing coating company in China. We are capable of producing 50,000,000 sqm waterproofing membranes and 20,000.00 MT waterproofing coating in one year. CNPW is committed to provide lients with best qualty products and excellent service.

Non-asphalt Polymer Waterproofing Membrane UnderlaymentNon-asphalt Polymer Waterproofing Membrane UnderlaymentNon-asphalt Polymer Waterproofing Membrane UnderlaymentNon-asphalt Polymer Waterproofing Membrane UnderlaymentNon-asphalt Polymer Waterproofing Membrane UnderlaymentNon-asphalt Polymer Waterproofing Membrane Underlayment





Send Inquiry to This Supplier

Message
0/5000
Want the best price? Post an RFQ now!
Business Type
Manufacturer
Year Established
2010
Factory Size
Above 100,000 square meters
Total Employees
101 - 200 People
