Fire and Flammability Testing Equipment
Standards
UL94,IEC60695-11-3,IEC60695-11-20,IEC60695-11-4,IEC60695-11-10
Application:
- When there is a fire around the products, should ensure that it will not to cause the spread of the fire, horizontal-vertical burning test simulates electronic products around the environment in the early condition, using the simulation technology to assess the fire risk.
- The test equipment apply to the electrical and electronic product components of household appliances, spare parts and components, such as: household appliances insulation shell, Panel switches, printed circuit boards and insulation materials and so on.
- Combustion chamber is composed by the test part and control part, using the integrated design, to facilitate the installation at the scene and debug. The shell of the test chamber and the important parts are all manufactured by stainless steel, resistant cigarettes and gas corrosion. The automatic degree of control system is high. Has automatic ignition, the products which were tested in both vertical and horizontal orientation has the function automatically follow flame in the cross of the test. Time and temperature figures show, so that the observation and records is facilitate and the use of it is stable and reliable.
Technical parameters:
Kinds |
500W(5V class ) | 50W(HB/Vclass) |
| Test Flame | 500W(burning test for V-0,V-1,V-2 classification) | 50W(burning test for V-0,V-1,V-2 classification) |
| Burner Tube | Internal diameter: Φ 9.5mm±0.3mm | Internal diameter: Φ 9.5mm±0.3mm, |
| Burning Angle | 0°,20°,45° | 0°,20°,45 ° |
| Thermocouple | Type K (Ni/Cr - Ni/Al) | Type K (Ni/Cr - Ni/Al) |
| Thermocouple Size | 0.5 mm | 0.5 mm |
| Standard Copper Block |
Φ9mm±0.01mm, weight:10g±0.05g before drilling. |
Φ5.5mm±0.01mm, weight.76g±0.01g before drilling. |
| Time for Temperature to Increase |
From 100°C±5°C to 700°C±3°C; 54s±2s (preset) |
From 100°C±5°C to 700°C±3°C; 44s±2s (preset) |
| Gas Flow | 965±32ml/min | 105±10ml/min |
| Gas Supply | methane,min.98% purity | methane,min.98% purity |
| water-column | 125m±5mm | ‹10mm |
| Test Time | 54±2s | 44±2s |
| Flame Height Indicator | 40±1mm | 20±1mm |
| Volume Of Chamber | >0.5m³, black interior | >0.5m³, black interior |
| Conform to standard | UL94,IEC60695-11-3,IEC60695-11-20 | UL94,IEC60695-11-4,IEC60695-11-10 |
Best Service and Advantages from Autostrong:
- High qualitty,Long life time and Competitive price
- Best after service:Professional R&D and technical team support,can make OEM & ODM order,and also can provide overall laboratory solutions,and good service.
- Strict quality control,more than 24hours befroe shipping and with 1year warrant
- Short leadtime and fast delivery
- With CE,ROHs,SGS and ISO certificates
Packaging: Packed with strong wooden case for Combustion chamber
Shipping Method: Express/By Air/By Sea
HONGKONG AUTOSTRONG TECHNOLOGY CO,.LTD
HONGKONG AUTOSTRONG TECHNOLOGY CO,.LTD is a high-tech company in Hongkong,who is engaged in research and development,manufacture of test instrument,whose headquater is in Kowloon,Hongkong,with branch offices in Shenzhen.
AUTOSTRONG is one of leading enterprises in Hongkong on R&D and manufacture of testing instruments.we supply standard or customized solutions and products for many test,measurement and quality control tasks required in the world of cable,wire,socket,plug,switch,plastic and rubber testing.All of our products are complying with the requirements of many standards,such as IEC,UL,VDE,VS,JIS,GB and so on.
Products include:Glow wire tester, Needle flame tester, horizontal and vertical burning tester, tracking tester,textile burning tester,protective clothing thermal conductivity tester,automotive interior combustion tester ,melt dripping tester,building materials flammability tester,friction tester,test finger,spring hammer,universal testing machinge and other testing instruments.
AUTOSTRONG strategic cooperation with Germany WAZAU,Germany PTL company,Germany FISCHER,Japanese minebea,and on going technical exchange.
AUTOSTRONG spirit:integration of science and wisdom,quality and service co-exist,face to the world,to achieve a win-win for the supply and demand.
