Help CenterJSM52A High Speed & Motor Style Flat Knitting Machine
Related Products
-
Good Quality Low Price Single System Single Carraige Flat Knitting MachineUS$ 3895.00 - 3895.00MOQ: 4 Sets -
Hot Sales Single Carriage Single System Sweater Automatic Knitting MachineUS$ 3895.00 - 3895.00MOQ: 4 Sets
-
Single Carriage Single System High Speed Automatic Flat Knitting MachneUS$ 3895.00 - 3895.00MOQ: 4 Sets
-
Cixing GE Series Flat Knitting MachineUS$ 8397.00 - 8397.00MOQ: 2 Sets
-
High Quality 52 Inches Computerized Flat Knitting MachineUS$ 8397.00 - 8397.00MOQ: 2 Sets
Machine details:
1. single carriage single system
2. 52 inches
3. 7G 9G 12G 14G 15G
4. motors control cam
5. Ruineng & Hengqiang system
Product Specification :
Knitting Gauge: 7G 9G 12G 14G 15G
Knitting Range: 44,52,60,80 (Inches)
Knitting Speed: Controlled by servo motor, 32 sections speed optional, max 1.2M/S.varies according to gauge and knitting condition
Knitting System: Single carriage with single systems
Knitting Function: Knit,miss,tuck,transfer,pointel,intarsia,jacquard,hide,or apparent shaping and other regular or irregular patterns
Racking: Controlled by servo motor racking within 2 inches and with fine adjusting function.
Protection: The machine will automatically alarm if yarn-breaking, knots ,floating yarn, rewinding of knitting, fail of racking needle, breakage error and programming occur.
Encoder: Advanced encoder is used to observe the needle.
Transfer: motors control cams to work.single system can achieve to transfer,miss,tuck and knit.
Stitch system: Controlled by stepping motor, 32 section stitch selectable, adjustable scope supported by subdivision technology: 0-650, the stitch of the knitwear can be accurately controlled.
Sinker system: Controlled by stepping motor, adjustable to different knitwear, have various results of shapping and patterns.
Takedown roller: Programmed instruction,controlled by marching motor, changeable 32 levels and selectable scope: 0-99.
Yam feeders: 6 Yarn carriers on each side of 3 guide rails, shiftable on any needle
website: our product have got the high reputation in local market.we are looking for agent from the global .
