ZGKSC 2015 Tank Oil Trailer

Product Name

3 axle 59000 litres LPG  tanker semi trailer

Model

HHT9401LPG

Brand Name

Hongtai

External Dimension (L×W×H) (MM)

13000*2500*3990

Total Weight(KG)

40000

Rated Payload(KG)

25000

Complete Vehicle Kerb Mass(KG)

14913

Test pressure

2.1MPA

MAWP

1.61MPA

X-RAY

100%

No.and brand of Axles(PC)

3 or 2,Fuwa or BPW or York or other customer need

Axle Base(MM)

5890+1310+1310, 5690+1310+1310

Front/Rear Overhang(MM)

-/1840, -/2040

Approach/Departure Angle(°)

-/17, -/15

Rated Loading Weight of The Saddle(KG)

16000

No. of Leaf Spring(PC)

-/8/8/8,-/10/10/10

Rear Wheel Track(MM)

1840/1840/1840

Working temperature(°C)

-19~50

Kingpin

JOST 2.0” or 3.5”

Landing Leg

JOST two speed linkage

Suspension

Leaf spring suspension, Single-point suspension, Air suspension

No. and brand of Tire(PC)

12,Triangle or Linglong or Double Coin or other customer need

Tire Specification

11.00-20,12.00-20,11.00R22.5,12.00R22.5,295/80R22.5,315/80R22.5,

385/65R22.5

Axle Load(KG)

-/24000(three axles are installed in parataxis)

Anti-lock Braking System

YES brand choosen from KEMI and Wabco

Electrical system

24V/12V,7pin ISO 1185 standard socket; two set of standard rear light ,turn light, rear reflector, side light, side reflector etc

Vehicle Identification Number

LA99CG40XXXHTGXXX

Painting

 One coat of anticorrosiv

Two coats of  finish urethane paint

 Colour as customer required

 Sand blasting processing on rust cleaning

Spare part

Manhole with 580mm diameter

Relief Valve

Emergency off valve

Liquid indicator

Pressure gage

Removable rails

Relay Valve
