Air Cooling 355nm Uv Laser Marking Machine for Sale
US$ 5,000 - 10,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Laser Type:
Other, UV laser, UV laser
CNC or Not:
Yes
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Long-Term Work Stable 355Nm Uv Laser Marking Machine for SaleUS$ 5,000 - 10,000MOQ: 1 Set -
3W Precision UV Laser Carver With High QualityUS$ 20,000 - 39,000MOQ: 1 Set
-
3W Precision UV Laser Marker for Mobile Phone PartsUS$ 20,000 - 39,000MOQ: 1 Set
-
3W Precision UV Laser Engraving Machine for Capacitive Touch Screen With High QualityUS$ 20,000 - 39,000MOQ: 1 Set
-
3W Precision UV Laser Etching Machine for Capacitive Touch Screen With High QualityUS$ 20,000 - 39,000MOQ: 1 Set
Condition
New
Laser Type
Other, UV laser, UV laser
CNC or Not
Yes
Cooling Mode
Air Cooling
Control Software
Ez-Cad
Graphic Format Supported
AI, BMP, DST, DWG, DXF, DXP, LAS, PLT
Working Accuracy
High precision
Place of Origin
Hubei, China
Brand Name
Huahai Laser
Model Number
HM1U HM3U
Power(W)
1W 3W 5W 7W
Certification
CE, ISO
After-sales Service Provided
Engineers available to service machinery overseas
Huahai Laser UV Laser Marking Machine Introduction
UV laser is a kind of cold light, mainly used in super precise marking and
engraving, particularly suitable for food, pharmaceutical packaging material
marking, micro punching, glass high-speed dividing, silicon wafer complex
graphics cutting, etc.
Main Features of Fiber Laser Marking Machine
-
High-fine quality marking
- Adopting diode side- pump laser as pump source, provide good beam quality .
- Marking head with high-precision gavol , it can get good quality effect and repeat marking.
- Whole sealing optical system and constant temperature,which make the whole equipment more stable, output facula diameter is smaller.
Widely applicable fields.
- Maximum 7000mm/s marking speed make the processing efficiency
- Special suitable for high precision and high speed marking .
- Suitable to mark on all kinds of metal and partial nonmetallic material.
- Can be obtained the underlying function of online flying marking and rotary marking through the mix parts.
Flexible and convenient operating system
- Humanized operation,stable running
- Special control software is compatible with AutoCAD, CorelDRAW, Photoshop and other software output
- It can realized automatic edition and correction of characters, signs, graphs, images, bar codes, two-dimensional codes, automatically increased serial numbers
- It can support various file formats like PLT,PCX,DXP,BMP,JPG and so on.
Low running and maintenance cost
- Long life ,stable performance and maintenance –free.
- Good stabilization
- Electro-optical conversion efficiency, saving electricity costs.
- Small, space-saving.
Technical Parameter Of UV Laser Marking Machine
| Laser Source | UV Laser |
| Output Power | 1W, 3W, 5W,7W |
| Wavelength | 355nm |
| Beam Quality | <2 |
| Repeat Frequency | 10khz--- 100khz |
| Pulse Energy | 2mJ |
| Beam Divergence | -0.3 to +0.3mrad |
| Laser Class | IV |
| Resolution | 18μ |
| Repeatablility | 50μ |
| Marking Scope | 50*50mm 100x100mm |
| Linear Speed | 800 character/ s |
| Marking Linear Speed | ≤12,000mm/s |
| Marking Depth | Max. 1.0- 1.5mm (hard steel) |
| Min. Line Width | 0.012mm |
| Min. Character Size | 0.15mm |
| Repeat Accuracy | ±0.003mm |
| Input Power | 0.5kw |
| Electrical Source | 220V / Single-Phase Circuit / 50/60Hz /4A |
Solutions For Differnt Industry
- Electrical Engineering and Electrical part and component
- Mobile (Cover,battery,keyboard, I Phone Case)
- Jewellery(Ring,pedeant,bracelet),eyeglass,clocks and craft
- Building materials,PVC pipe
- Car motor car spare part ,Insturment and meters and cutting tool
- Plastic case,aviation and aerospace,
- Military product,hardware fitting and accessory,sanitary appliance
- Food and beverage ,Medicine package and medical instrument,solar PV industry
Sample Of Fiber Laser Marking Machine
Details Of Packing and Shipping
1.Durable wooden case or as per required.
2.The delivery lead time would be 5-7 working days after recieving the payment.
3.As for the wholsalers/distributors, we could send the cargo by air, by sea or by railways via reliable forwarder.
