1.Water filter cartridge
2.Low pressure drop
3.High flow rate
4.Made in a clean room
5.Experiencing 100% integrity test
6.Food grade
Material |
Membrane |
PP fibre membrane |
Core |
Polypropylene |
|
O ring/Gasket |
PP |
|
Specifications |
Pore size (um) |
0.1 / 0.2 / 0.45 / 0.65 / 1 / 3 / 5 / 10 / 20 / 30 / 60 |
Outer Diameter (OD) |
69mm |
|
Length (inch) |
4,5,10,20,30,40,50 |
|
End cap |
DOE(decided by client) |
|
Technical data |
Effective filtration area |
0.40-0.70 M2 |
Max. back pressure |
0.28Mpa 60°C |
|
Max. working temperature |
80°C, 0.28MP |
|
Max. differential pressure |
0.42Mpa 25°C |
|
Max. bear temperature |
140°C,0.28Mpa |
|
Sterilization method |
121°C 30min |
Excellent performance of chemical compatibility
Better performance removal rating meets all-purpose application
Hot melting seal enhances the strength and reduce the dissolved matter
Pleated design provides high dirt holding and suspended solids capture
General purpose:R.O. system pre-filtration, Deionized water pre-filtration.
Food and Beverage:Drinking water, Beer, Mineral water, Wines, Beverage.
Chemical: Filtration of Solvent, Acid, Alkali, Amine and etc.
Pharmaceutical: Filtration of Medicine, Biology, Plasma, Compressed Air and Gas.
General Industries:Filtration of Electroplate liquid, Metal machining liquid and Magnetism medium.
Model information
| Cartridge Type | Micron Ratings | Filter Media | Length | Gasket/ O-ring | End Cap |
| 1. PPMP:PP Membrane pleated filter cartridge | 0.1um | 1.PP Polypropylene | 5" | S:Silicone | A:Flat Gasket Double Open End |
| 0.22um | 10" | E:EPDM | B:222 O-rings/ Flat End | ||
| 0.45um | 20" | N:NBR | C:226 O-rings/ Flat End | ||
| 0.65um | 30" | V:Viton | D:222 O-rings/ Fin | ||
| 1um | 40" | E:226 O-rings/ Fin | |||
| 3um | Other Customized Sizes | ||||
| 5um | |||||
| 10um | |||||
| 30um | |||||
| 60um | |||||
