Product Description
| Item Code: | WJ117-1 |
| Material: | nylon,plastic steel |
| Specification: | 2ml 5ml |
| Manufacturer: | Shaoxing Wanjia Appliance Co.,Ltd |
| Orignal Of Place: | Shaoxing,Zhejiang,China |
| Color | according to your need |
| Features: |
1. New design 2. gun shape, easy to use. 3. have a good grip. 4. automatic . |
How to use the syringe?
To fit needle
1. Safety-Leave protective cover on needle
2. Unscrew nozzle nut until nib is below cutout detail on nozzle nut
3. Insert needle base into cutout detail on nozzle nut
4. Hold needle in cutout and screw nozzle nut until firmly onto barrel
5. To remove needle replace protective cover.unscrew nozzle nut part-way until needle can be removed from cutout.
To Replace Bottle
1. In one hand using thumb and forefinger,squeeze retention grips firmly together
2. With the other hand grasp base of the bottle and pull firmly out of the fast-fit bottle mount
To attach a new bottle,repeat steps 1-3
To Set Dose
Align front of piston to desired dose setting printed on the barrel,by turning dose adjuster either clockwise or anti-clockwise
To Adjust Spring Handle Tension
To increase handle-spring tension:turn spring tension adjuster clockwise,all the way until firm
To reduce handle-spring tension:turn spring tension adjuster anti-clockwise until tension has been eased
Attention:
This products just can use Disinfection water to disinfect.Remembering that boils disinfection and the high pressure steam disinfection
Prodution line test:
1.With work team or data engineer who will inspect machines and linesat fixed period.
2.Finished Product Inspection:Quality and property test before productsare packed and loaded.
To Lubricate:
if plunger becomes sluggish Remove barrel and lubricate piston o-ring with olive or cooking oil
