Home > Products > Thrust Ball Bearing > High Precision Double Direction Thrust Angular Contact Bearing 234440M Used for Machine Tool Spindle
High Precision Double Direction Thrust Angular Contact Bearing 234440M Used for Machine Tool Spindle
- Shanghai China
- T/T L/C D/P D/A Money Gram Credit Card PayPal
You May Like
-
High Quality Double Direction Thrust Angular Contact Ball Bearing 234440M
-
Made in China Thrust Ball Bearing 51209 45*73*20 mm Bearing 8209
-
High Precision Thrust Ball Bearing 51204 Axial-Kugellager 51204
-
Superior Precision Thrust Ball Bearing for Vertical Centrifuge
-
China Supplier Thrust Ball Bearing 51204 20*40*14 mm
-
Thrust Ball Bearing 51204 for Water Pump
Product Details
| Brand Name | SYBR | Bore Size | 200, | |
| Outside Diameter | 310, | Model Number | 234440M | |
| Precision Rating | P0,P6,P5,P4 | Seals Type | Machined Brass Cage | |
| Number of Row | Single Row | Place of Origin | China |
Product Description
High Precision Double Direction Thrust Angular Contact Bearing 234440M Used for Machine Tool Spindle
The Brief Description of Double Direction Thrust Angular Contact Ball Bearings:
Double direction thrust angular contact bearing is the precision bearing which special design for the main of the machinery equipment. It can afford the loading of axial from two directions, if you compare with 511 series's thrust ball bearing the diameter of the steel ball inside the bearings is smaller, more quantity and they have 60 degree touching angle, so it will be more better for the high speed ratation, more.
Precautions for Proper Handling of Thrust Angular Contact Ball Bearings:
1.Keep bearings and surrounding area clear
Dust and dirt, even if invisible to the naked eye ,have harmful effects on bearings.It is necessary to prevent the entry of dust and dirt by keeping the bearings and their environment as clean as possible.
2.Careful Handling
Heavy shocks during handling may cause bearings to be scratched or otherwise damaged possibly resulting in their failure. Excessively strong impacts may cause brineling,breaking,or cracking.
3.Use proper tools
Always use the proper equipment when handling bearings and avoid general purpose tools.
4.Prevent Corrosion
Since perspiration on the hands and various other contaminants may cause corrosion, keep the hands clean when handling bearings. Wear gloves if possible. Pay attention to rust of bearing caused by corrosive gasses.
Double Direction Thrust Angular Contact Ball Bearing 234440M Details:
Bore diameter | 200mm |
Outside diameter | 310mm |
Width | 132mm |
Model | 234440M |
Tolerance | Normal (PN) |
Product performance | H&K |
Bore type | Tapered |
Number of rows | Two |
Cage | Sheet metal |
Sealing | None |
Radial internal clearance | Group 3 (C3) |
Locating feature - bearing outside | None |
Relubrication feature | With |
Lubricant (in bearing) | None |
Material/Treatment | Bearing steel |
Dimension type | Metric |
Double Direction Thrust Angular Contact Ball Bearings Pictures Show:
Double Direction Thrust Angular Contact Ball Bearings Specification:
| Bearing No | Dimension(mm) | C/C0(kN) | Mass(KG) |
| 234407 | 35×62×34 | 18.6/49 | 0.38 |
| 234408 | 40×68×36 | 21.6/60 | 0.46 |
| 234409 | 45×75×38 | 24.7/71 | 0.58 |
| 234410 | 50×80×38 | 25.5/78 | 0.62 |
| 234411 | 55×90×44 | 33.8/104 | 0.94 |
| 234412 | 60×95×44 | 34.5/108 | 1.00 |
| 234413 | 65×100×44 | 35.8/116 | 1.05 |
| 234414 | 70×110×48 | 43.6/143 | 1.45 |
| 234415 | 75×115×48 | 44.2/150 | 1.55 |
| 234416 | 80×125×54 | 54/180 | 2.10 |
| 234417 | 85×130×54 | 54/190 | 2.20 |
| 234418 | 90×140×60 | 62.4/220 | 3.00 |
| 234419 | 95×145×60 | 63.7/232 | 3.05 |
| 234420 | 100×150×60 | 66.3/245 | 3.15 |
| 234421 | 105×160×66 | 74.1/275 | 4.05 |
| 234422 | 110×170×72 | 92.3/335 | 5.05 |
| 234424 | 120×180×72 | 93.6/360 | 5.70 |
| 234426 | 130×200×84 | 117/455 | 8.15 |
| 234428 | 140×210×84 | 117/475 | 8.65 |
| 234430 | 150×225×90 | 140/570 | 10.50 |
| 234432 | 160×240×96 | 156/640 | 14.00 |
| 234434 | 170×260×108 | 195/780 | 17.50 |
| 234436 | 180×280×120 | 225/915 | 23.00 |
| 234438 | 190×290×120 | 225/950 | 24.00 |
| 234440 | 200×310×132 | 265/1100 | 31.00 |
Other Sereis Thrust Ball Bearings:
511 Series: 51118 51120 51122 51124 51126 51128 51130-MP 51132-MP 51134-MP 51136-MP 51138-MP 51140-MP 51144-MP 51148-MP 51152-MP 51156-MP 51160-MP 51164-MP 51168-MP 51172-MP 51176-MP 51180-MP 51184-MP 51192-MP 511/500-MP 511/530-MP 511/560-MP ……
512 Series: 51218 51220 51222 51224 51226 51228 51230-MP 51232-MP 51234-MP 51236-MP 51238-MP 51240-MP 51244-MP 51248-MP 51252-MP 51256-MP 51260-MP 51264-MP 51268-MP 51272-MP ……
513 Series: 51318 51320 51322-MP 51324-MP 51326-MP 51328-MP 51330-MP 51332-MP 51334-MP 51336-MP 51338-MP 51340-MP ……
514 Series: 51418-MP 51420-MP 51422-MP 51424-MP ……
532 Series: 53218 53220 53222 53224 53226 53228 53230-MP 53232-MP 53234-MP 53236-MP 53238-MP ……
533 Series:53318 53320 53322-MP
Bearings Package:
Original Package:
1):Inner Plastic Bag+ Paper Box + Carton(+Pallet);
2):Small sizes:Plastic Tube + Carton
3):Big sizes:Wooden Case
Bearings Lead time:
We will prepare your order as soon as possible.
1)2-3 days for ex-stock
2)6-10 days for others
Shipping & Delivery time:
1)Less than 45 Kg:DHL TNT Fedex UPS express will be better,( 4-7 days delivered to your address);
2) Between 45 to 200 Kg:Air transiportation will be better,( 5-14 days delivered to your airport);
3) Over 200 Kg:Sea transportation will be better.( Cheapest,18-45 days to your port ).
Payment terms:
We accept T/T, Western Union,Paypal,Visa.
1) T/T or WU (we undertake the bank fees):
A:100% payment.
B:30% deposit ,70% before transportation.
2)PayPal (we undertake the transaction fees) :
A:100% payment.
B:30% deposit ,70% before transportation.
3) L/C at sight.
Note :We will take some pictures of your Pillow block bearing UCF 206,UCF208,UCF211 before transportation.
| Price terms | Door to door,FOB,CNF,CFR,CIF,EXW,C&F |
| Shipping Airport | Shanghai Pudong International Airport |
| Shipping Port | Shanghai,Guangzhou |
Shanghai Shengyue Bearing Co., Ltd. is a professional China Angular Contact Ball Bearings manufacturer and dealer in China. We have been engaged in bearing industry for 15 years and worked on bearing import and export for more than 8 years. We attend international bearing fairs, put in many B2B websites and achieve many customers all over the world, building up a good reputation from our customers.
Bearings Produce Process and Factory Pictures:
If you are interested in our Double Direction Thrust Angular Contact Ball Bearings, please feel free to send an inquiry or chat with us online.
We will warmly reply you immediately!---SHR Bearing
