Universal cv Joint Bearing GE220ES-2RS Cross Joint Bearing

Universal cv Joint Bearing GE220ES-2RS Cross Joint Bearing thumbnail-1
Universal cv Joint Bearing GE220ES-2RS Cross Joint Bearing thumbnail-2
Universal cv Joint Bearing GE220ES-2RS Cross Joint Bearing thumbnail-3
Universal cv Joint Bearing GE220ES-2RS Cross Joint Bearing thumbnail-4
Universal cv Joint Bearing GE220ES-2RS Cross Joint Bearing thumbnail-5
Universal cv Joint Bearing GE220ES-2RS Cross Joint Bearing thumbnail-6
Universal cv Joint Bearing GE220ES-2RS Cross Joint Bearing photo-1
Universal cv Joint Bearing GE220ES-2RS Cross Joint Bearing photo-2
Universal cv Joint Bearing GE220ES-2RS Cross Joint Bearing photo-3
Universal cv Joint Bearing GE220ES-2RS Cross Joint Bearing photo-4
Universal cv Joint Bearing GE220ES-2RS Cross Joint Bearing photo-5
Universal cv Joint Bearing GE220ES-2RS Cross Joint Bearing photo-6
US$ 12.5 - 45.5 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
NACHI
Bore Size:
0, 220
Outside Diameter:
0, 320
Contact Supplier Request Quote Chat Now
Shanghai Shengyue Bearing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Qingdao /as request
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name NACHI
Bore Size 0, 220
Outside Diameter 0, 320
Model Number bearing GE220ES-2RS
Precision Rating p0,p6 p5 p4
Seals Type open/ seal
Place of Origin Shanghai, China

Universal cv joint bearing GE220ES-2RS cross joint bearing







*Manufacturer factory price

*OEM service offer

*Different kinds of oscillating bearing

*GEG,GE,GEZ series
*ISO9001:2008 standard

*Sample available



Product Description

Universal cv joint bearing GE220ES-2RS cross joint bearing information as below :

Model   d   D    B   Weight/KG
GE 15 ES 2RS 15

26

 12    0.027
GE 17 ES 2RS 17 30 14 0.041
GE 20 ES 2RS 20 35 16 0.066
GE 25 ES 2RS 25 42 20 0.119
GE 30 ES 2RS 30 47 22 0.153
GE 35 ES 2RS 35 55 25 0.233
GE 40 ES 2RS 40 62 28 0.306
GE 45 ES 2RS 45 68 32 0.427
GE 50 ES 2RS 50 75 35 0.546
GE 60 ES 2RS 60 90 44 1.04
GE 70 ES 2RS 70 105 49 1.55
GE 80 ES 2RS 80 120 55 2.31
GE 90 ES 2RS 90 130 60 2.75
GE 100 ES 2RS 100 150 70 4.45
GE 110 ES 2RS 110 160 70 4.82
GE 120 ES 2RS 120 180 85 8.05
GE 140 ES 2RS 140 210 90 11.02
GE 160 ES 2RS 160 230 105 14.01
GE 180 ES 2RS 180 260 105 18.65
GE 200 ES 2RS 200 290 130 28.03
GE 220 ES 2RS 220 320 135 35.51
GE 240 ES 2RS 240 340 140 39.91



Universal cv joint bearing GE220ES-2RS cross joint bearing

cross joint bearing designs :

(1) GE ... E every single outer ring, no oil tank. Able to support radial load and smaller in

either direction axial load.



(2) GE ... EStype outer ring slit, a lubricating oil tank. Able to support radial load and smaller in either

direction axial load.



(3) GE ... ES2RS outer single slit, a lubricating oil tank, both sides with a ring. Able to support radial load and

smaller in either direction axial load.



(4) GEEW ... ES2RS outer single slit, a lubricating oil tank, both sides with a ring. Able to support radial load and

smaller in either direction axial load.



(5) GE ... ESN single slit the outer ring, a lubricant tank, the outer ring groove. Able to support radial

load and smaller in either direction axial load. But the axial load to bear by the stop ring, its ability

to reduce the axial load.





Advantages of Universal cv joint bearing GE220ES-2RS cross joint bearing :

1.Can bear large load

2.Different types and structures

3.Self-lubricating

4.Used for low speed pendulum motion and low-speed rotation

5.Can do tilting motion in a certain angle range

6.Have bigger load capacity and impact resistant ability

7.Resist corrosion, resistant to wear , self aligning , good lubrication

8.Can work normally even installation dislocation



Bearing pictures

Universal cv joint bearing GE220ES-2RS cross joint bearing pictures :

Universal cv joint bearing GE220ES-2RS cross joint bearingUniversal cv joint bearing GE220ES-2RS cross joint bearingUniversal cv joint bearing GE220ES-2RS cross joint bearing



BEARING APPLICATION

Widely used in metallurgy ,mining ,petroleum,chemical,coal,cement ,paper,windpower,heavy machinery ,enginnering machinery,port machinery and other industries.



A.Road machinery
B.Earthwork machinery

C.Material handling machiney

D.Train

E.Power equipment

F.Automobile

G.Solar energy

H.Wind power

I.Metallurgical equipment

J.Aerospace

K.Ship&Port machinery

L.Mining machinery

M.Packaging machinery

N.Bridge & Water gate

O.Printing machinery

P.Food machinery

Universal cv joint bearing GE220ES-2RS cross joint bearing



BEARING KNOWLEDGE

 Know more about our bearings :

1. Inspection of bearing and judgment :

In order to determine whether removing bearings can be used to check after the bearings clean, carefully check the roller surface, scroll, status of the mating surfaces, wear of the cage, the increase in bearing clearance and there's no falling damage, abnormal size precision. Non-separation of small ball bearings, supporting inner rings with one hand horizontally, rotate the outer ring to confirm in a smooth rotation State. Tapered roller bearings are separable bearings, rolling element and the Raceway in the outer ring can be respectively checked. Larger bearings cannot rotate, check rolling element and the Raceway, cage, sidewall surface appearance. the importance of as high as possible shall be carefully inspected.



2 .Bearing damage reasons analyse :

Universal cv joint bearing GE220ES-2RS cross joint bearing



Company introduction

Our company information :

Company name                     shanghai shengyue bearing Co.,Ltd
Business type                                   manufacturer
Established year                                          2012
Business product                              all kinds of bearings
OWN Brand                                            SHR
Export range                                        81%-90%
OEM service                                            offer
     Our                                           advantages

1. More than ten years bearing products exporting experiences.

2. OEM order and non-standard bearing order can be accepted.

3. Many sizes of bearing are available. Large quantity bearing can be provided.

4. A certain number of free sample can be provide to support our customer's after-sale services and warranty.



Trading information :

Price terms

                             EXW FOB CNF CFR, CIF
Payment terms                               L/C ,T/T ,Western Union, Paypal
Express way                              DHL FEDEX TNT UPS
Shipping port                         shanghai ,qingdao ,nongbo, guangzhou
Packing

1.Industrial packaging: plastic bag + kraft paper + carton + plywood pallets;

   plastic tube + carton + plywood pallets;

2. Commercial packing: 1pc/plastic bag + color box + carton + plywood pallets

 Our Factory :

Universal cv joint bearing GE220ES-2RS cross joint bearing

 How a bearing be made out ? ---- Production procedures :

Universal cv joint bearing GE220ES-2RS cross joint bearing

How we test the bearings ?

Universal cv joint bearing GE220ES-2RS cross joint bearing

Shipping express we cooperated :

Universal cv joint bearing GE220ES-2RS cross joint bearing

 Bearing catalog :

Universal cv joint bearing GE220ES-2RS cross joint bearingUniversal cv joint bearing GE220ES-2RS cross joint bearing

For any questions, please find us !

Universal cv joint bearing GE220ES-2RS cross joint bearing



Universal cv joint bearing GE220ES-2RS cross joint bearing



Contact with us :

==================================================================================

Shanghai Shengyue Bearing Co.,Ltd
Contact : Ms. Alice Xiong

Skype : alice.bear01

Tel:+86 18701870126

Email :shr0374(at)

Web:http://shr-bearing.en.china.cn/

Address: Room701,Yizheng Building,No.681 Xincun Road,Putuo District. Shanghai,China.

==================================================================================
