Specifications
YZ5T, which chooses professional digital camera, is specially designed for anterior segment photograph. The high pixel and high-YZ5T, which chooses professional digital camera, is specially designed for anterior segment photograph. The high pixel and high-definition images of this products provides true, accurate and reliable basis to eye doctors in clinic and clinical research. The image system function of it is strong and easy to use. It is a good helper of ocular clinical diagnosis. |
Features:
·Professional acquisition
The instrument adopts the SLR camera as the medium of acquisition which can provide real-time dynamic display wich the highest 18 million pixels. The image is clear and the acquisition speed is quick
·New optical system
The optical system is specially designed for anterior segment photography . The field of view is open and the vision is clear and bright. The shape is concise and fluent.
·Take Picture quickly
Shooting unit locates in the top of the control handle. Focus on the lesion, press the button and get the clear image immediately.
·Powerful image processing functions
Can measure length, area, Angle, grayscale, curvature, etc., and can mark lesions and add text on the image lesions.
·Fixation lamp-bias light: one-piece lighting
Background lighting device can provide more than 150000 lx, and accompany with fixation lamp lighting function. It can let the details more clearly when you take a photo.
·High-definition images
The instrument can take pictures up to 18 million pixels, and provides up to 40 times magnification. It is able to show the micro details and meet the requirements of medical image, provide us the more clearly lesion progress.
·Auxiliary function of diagnosis
Offers a variety of diagnosis mode parameter settings of common eye diseases, improves the efficiency of diagnosis.
·Can choose built-in CCD as the medium of acquisition
Choose professional CCD for medical use which is with high sensitive, high resolution ratio. Provide a better color reducibility, and the picture will be more shape and its picture quality will be better.
Have tow image acquisition modes: static images and dynamic image image. It can not only store photos, but also can record all the diagnosis process;
Built-in CCD design makes the outward appearance more concise and easy. The product is with more stable reliability, which can effectively avoid external man-made influence on instrument, enhance the security and stability;
Parameter can be automatically adjusted and,joystick buttons is a key to get a clear image and video. The whole operation is more convenient.
Technical parameters:
Type |
Parallel Angle(Galileo type) |
Zoom methods |
Drum 5-Speed Zoom |
Eyepiece |
12.5X |
The total ratio and field of view |
6 x (33mm) 10x(22.5mm) 16x (14mm) 25´ (8.8mm) 40´(5.5mm) |
Pd regulating range |
55 mm~75 mm |
Diopter Adjustment |
-5D ~ +3D |
Slit width |
0mm~14mm Continuing Adjust |
Slit height |
1mm~14mm Continuing Adjust |
Spot diameter### |
φ14mm,φ10mm,φ5mm,φ2mm,φ1mm,φ0.2mm |
Filter |
Heat insulation film, light reduce film,red free film , cobalt blue pills |
Lighting Lamp |
12v/30w Tungsten halogen light bulb |
Maximal Lighting### |
≥28 thousand Lx |
Fill-in light Method### |
Bias Light |
Medium of acquisition |
SLR Camera or CCD for Professional Medical Use |
Pixel |
18 million |
Display method### |
Double screen real-time dynamic display or single screen real-time dynamic display |
lifting platform |
YT2GA high-level lifting platform |
Software function### |
Medical Record Store. Picture Processing, Measurement,Auxiliary Diagnosis,etc. |
