Japan original needle roller bearing with Inner Ring NA4905
The Brief Description of Needle Roller Bearing NA Series Details:
| Name | Needle Roller Bearing NA4905 |
| Material: | GCr15,GCr15 SiMn , G20Cr2Ni4A |
| Bore Size: |
10mm-30mm & Special diameter Upon the customers' request |
| Main Market: | North & south America, European countries, Middle East |
|
Physical Characteristics: |
1) needle bearing can be separated by single row. |
|
2) This kind of bearing can be submitted to high radial load and some axial load. | |
| 3) The rolling element of needle roller bearing is needle, | |
|
the two ends of the external lines have the corrective slope which can eliminate the contact stress. | |
|
4) Moreover, we can manufacture these bearings according to customer's drawings and samples | |
| Application |
Motor, Machinery, Electric Tools, Sports Apparatus, medical equipment, chemicals, aviation, perfume bottles, sprayers, valves, nail polish, body jewelry, mobile phone panels, toys, etc.
|
Pictures Shows of needle roller bearing NA 4900 Series:
More Model Numbers of Needle Bearing Specification:
| NA Model | Boundary dimensions(mm) | Weight(g) | ||
| d | D | C | ||
| NA 4900 | 10 | 22 | 13 | 24.3 |
| NA 4901 | 12 | 24 | 13 | 27.6 |
| NA 6901 | 24 | 22 | 46.9 | |
| NA 4902 | 15 | 28 | 13 | 35.9 |
| NA 6902 | 28 | 23 | 63.7 | |
| NA 4903 | 17 | 30 | 13 | 39.4 |
| NA 6903 | 30 | 23 | 69.9 | |
| NA 4904 | 20 | 37 | 17 | 79.9 |
| NA 6904 | 37 | 30 | 141 | |
| NA 49/22 | 22 | 39 | 17 | 85.4 |
| NA 69/22 | 39 | 30 | 151 | |
| NA 4905 | 25 | 42 | 17 | 94.7 |
| NA 6905 | 42 | 30 | 167 | |
| NA 49/28 | 28 | 45 | 17 | 104 |
| NA 69/28 | 45 | 30 | 183 | |
| NA 4906 | 30 | 47 | 17 | 108 |
| NA 6906 | 47 | 30 | 191 | |
| NA 49/32 | 32 | 52 | 20 | 168 |
| NA 69/32 | 52 | 36 | ||
| NA 4907 | 35 | 55 | 20 | 181 |
| NA 6907 | 55 | 36 | ||
| NA 4908 | 40 | 62 | 22 | 240 |
| NA 6908 | 62 | 40 | ||
| NA 4909 | 45 | 68 | 22 | 284 |
| NA 6909 | 68 | 40 | ||
| NA 4910 | 50 | 72 | 22 | 287 |
| NA 6910 | 72 | 40 | ||
| NA 4911 | 55 | 80 | 25 | 416 |
| NA 6911 | 80 | 45 | ||
| NA 4912 | 60 | 85 | 25 | 448 |
| NA 6912 | 85 | 45 | ||
| NA 4913 | 65 | 90 | 25 | 479 |
| NA 6913 | 90 | 45 | ||
| NA 4914 | 70 | 100 | 30 | 762 |
Needle Roller Bearing Needle bearing series:
| Needle bearing series | |
|
Drawn cup needle roller bearings |
HK Series BK Series Inch Series |
|
Sealed drawn cup needle roller bearings |
HK...RS Series HK...2RS Series BK...RS Series |
|
Drawn cup full component needle roller bearings |
F Series FH series MF Series MFH Series FY Series |
|
Drawn cup roller clutches/ clutch and bearing assemblies |
HF Series HFL Series |
Radial needle roller and cage assemblies |
K Series K...ZW Series |
|
Radial needle and cage assemblies for pin connecting rod |
KZK Series KBK Series |
| Heavy duty needle roller bearings |
NK Series NKS Series RNA49 Series RNA69 Series NKI Series NKIS Series NA49 NA69 NA48 NAO RNAO series |
Sealed heavy duty needle rollers bearings |
RNA49...RS/2RS NA49...RS/2RS |
Full components needle roller bearings |
RNAV series RNV Series |
| Self-aligning needle roller bearings |
RPNA/PNA Series IR/LR Series IXK Series |
More Needle Roller Bearing Models :
HK0408TN HK0509 HK0607 HK0608 HK0609 HK0611 HK0808 HK0810 HK0908 HK0910 HK0911 HK0912 HK1010 HK1012 HK1015 HK1208 HK1210 HK1212 HK1311 HK1312 HK1410 HK1412 HK1416 HK1512 HK1514 HK1515 HK1516 HK1522 HK1612 HK1614 HK1616 HK1617 HK1622 HK1712 HK1714 HK1716 HK1718 HK1812 HK1816 HK2010 HK2011 HK2012 HK2014 HK2016 HK2018 HK2020 HK2025 HK2030 HK2210 HK2212 HK2216 HK2220 HK2230 HK2512 HK2514 HK2516 HK2518 HK2520 HK2525 HK2526 HK2538 HK2816 HK2818 HK2820 HK3012 HK3016 HK3018 HK3020 HK3026 HK3028 HK3224 HK3232 HK38*48*30 HK40*50*32 HK40*50*38 HK45*55*38 HK50*57*16 HK50*60*38 BK3012 25941/30 HMK3020 HK30X38X16 7941/30 HMK3220 BK3512 HMK3530
HK3016 47941/30 HK3024 HK30X38X24 7942/30 HK3224 HK3516 HK35X42X16
BK3016 45941/30 HMK3025 HK30X38X32 7943/30 HK3232 BK3516 HK3524
HK3018 57941/30 HK3026 BK3530 HK35X43X25 HK32X19X16 HK3520 HMK3030
HK3020 67941/30 BK3026 HK3530 HK35X43X32 HK32X40X32 BK3520 HK3038
BK3020 65941/30 HK3030 HMK3520 HK35X45X12 HK32X41X16 HK3520/ASI BK3038
HF0306,HF0406,HF0608,HF0606,HF0612,HF0812,HF1012,HF1216,HF1416,HF1616 HF1816 HF2016 HF2520 HF3020 HF3520 HFL0408KFR HFL0615KFR HFL0822KFR HFL1226KFR HFL1626 HFL1826 HFL2026 HFL2530 HFL3030 HFL3530HF0306,HF0406,HF0608,HF0606,HF0612,HF0812,HF1012,HF1216,HF1416,HF1616 HF1816 HF2016 HF2520 HF3020 HF3520 HFL0408KFR HFL0615KFR HFL0822KFR HFL1226KFR HFL1626 HFL1826 HFL2026 HFL2530 HFL3030 HFL3530
Bearings Package of needle bearing NA 4900 Series:
Original Package:
1):Inner Plastic Bag+ Paper Box + Carton(+Pallet);
2):Small sizes:Plastic Tube + Carton
3):Big sizes:Wooden Case
Bearings Lead time of needle bearing NA 4900 Sereis:
We will prepare your order as soon as possible.
1)2-3 days for ex-stock
2)6-10 days for others
Shipping & Delivery time of needle bearing NA 4900 Series:
1)Less than 45 Kg:DHL TNT Fedex UPS express will be better,( 4-7 days delivered to your address);
2) Between 45 to 200 Kg:Air transiportation will be better,( 5-14 days delivered to your airport);
3) Over 200 Kg:Sea transportation will be better.( Cheapest,18-45 days to your port ).
Payment terms of needle bearing NA 4900 Series:
We accept T/T, Western Union,Paypal,Visa.
1) T/T or WU (we undertake the bank fees):
A:100% payment.
B:30% deposit ,70% before transportation.
2)PayPal (we undertake the transaction fees) :
A:100% payment.
B:30% deposit ,70% before transportation
3) L/C at sight.
Note :We will take some pictures of your IKO bearings before transportation.
| Price terms | FOB,CNF,CFR,CIF,Door to door |
| Shipping Airport | Shanghai Pudong International Airport |
| Shipping Port | Shanghai,Guangzhou |
If you are interested in our products of needle bearing NA4905,please feel free to send an inquiry or chat with us online.
We will warmly reply you immediately!---SHR Bearing
