rf Pcb Circuit Board for Beauty Machine

US$ 50 - 60 MOQ: 1 Square Meter

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

tws

Model Number:

2012022006

Shenzhen Tianweisheng Electronic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name tws

Model Number 2012022006

Base Material FR4

Copper Thickness 1OZ

Board Thickness 1mm

Min. Hole Diameter 0.15mm

Min. Line Width 0.2mm

Min. Line Spacing 0.2mm

Surface Finishing HASL

1.Single entrance guard machine the mainboard 2.UL,SGS,ROHS,IS09001,CEC 3.Fast delivery with high quality 4.20years in PCB

1.Single entrance guard machine the mainboard 2.UL,SGS,ROHS,IS09001,CEC 3.Fast delivery with high quality 4.20years in Pinted circuit board

5.doorbell pcb

Welcome to.......Tian Wei Sheng

We manufacture Printed Circuit Board:High quality with competitive price(Good tolerance,Good warpage,Good solderable...)

The information about our company's process capacity for your reference:

	Specification Inch (mm)
Material	FR-4 / Hi Tg FR-4 / Lead free Materials (RoHS Compliant) /CEM-3/CEM-1/Aluminium
Layer No.	1-30
Board thickness	0.015"(0.4mm)-0.125"(3.2mm)

Board Thickness Tolerance	±10%
Cooper thickness	1/2OZ-3OZ
Impedance Control	±10%
Warpage	0.075%-1.5%
Peelable	0.012"(0.3mm)-0.02’(0.5mm)

Min Trace Width (a)	0.005"(0.125mm)
Min Space Width (b)	0.005"(0.125mm)
Min Annular Ring	0.005"(0.125mm)
SMD Pitch (a)	0.012"(0.3mm)
BGA Pitch (b)	0.027"(0.675mm)
Regesiter torlerance	0.05mm

Min Solder Mask Dam (a)	0.005"(0.125mm)
Soldermask Clearance (b)	0.005"(0.125mm)
Min SMT Pad spacing (c)	0.004"(0.1mm)
Solder Mask Thickness	0.0007"(0.018mm)

Hole size	0.01"(0.25mm)-- 0.257"(6.5mm)
Hole Size Tol (+/-)	±0.003"(±0.0762mm)
Aspect Ratio	6:1
Hole Registration	0.004"(0.1mm)
Plating
HASL	2.5um
Lead free HASL	2.5um
Immersion Gold	Nickel 3-7um Au:1-3u''
OSP	0.2-0.5um
Outline
Panel Outline Tol (+/-)	±0.004''(±0.1mm)
Beveling	30°45°
V-cut	15° 30° 45° 60°
Certificate	ROHS ISO9001:2000 TS16949 SGS UL
