Home > Products > Shadowless Lamps Slit Lamps > Medical Shadowless Operation Lamp(LOTUSLED-Z75)

Medical Shadowless Operation Lamp(LOTUSLED-Z75)

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 200 Set / Sets per Month
Port NANJING SHANGHAI OR NINGBO
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Type:	Shadowless Lamps	Brand Name:	CHEVY MEDICAL,LOTUS OR OEM	Model Number:	LOTUSLED-Z75
Place of Origin:	Jiangsu, China

Product Description

Specifications

50,000 hours life
3500K,4000K,45000K adjustable
Focus adjustable electrically
Ra=95,R9=93
Low temperature incr

Medical Shadowless Operation Lamp (LOTUSLED-Z75 )

Product Description

LOTUSLED.Z7/5 shadowless operation lamp is suitable for the requirements of operation conditions and ideal operating lighting equipment for modern operation rooms

Features:

1,An imported LED cold light source is adopted as operation lighting. As a genuine cold light source, there is almost no temperature rise at the doctor’s head or the wound.

2,The white LED has a feature of color temperature which is different from the light source of common shadowless lamps for operation. It may enhance the chromatic aberration between blood, other body tissues and organs, and it thus helps the operating doctor to have a clearer view.

3,Digital means are adopted for stepless regulation of LED brightness. The operator may adjust the brightness based on his/her own brightness adaptability.

4,The color temperature can be adjusted as preferred or according to the type of surgery.

5,The imported switch power supply is adopted to control the voltage, making the work voltage permanently stable.

6,A special optical system is adopted so that the light is evenly illuminated on the observed objects in 360∑, without any virtual image and with high definition.

TECHNICAL SPECIFICATION:

Technical Data (in 1m distance)	LOTUSLED-Z7	LOTUSLED-Z5
1,Diameter of light heads [mm]	780	610
2,Max Central Illuminance at 4,500 K [Lux]	180,000	160,000
3,Illuminance Measured Adjustable [Lux]	6,0000-180,000	6,0000-160,000
4,Colour temperature (standard) [K]	4500	4500
5,Color temperature Adjustable [K]	3500, 4000, 4500	3500, 4000, 4500
6,CRI (Color rendering index) [Ra]	≥95	≥95
7,Red Color Index (R9) [R9]	≥93	With out (R9)
8,Light Field, d10 [mm]	180±15	160±15
9,Light Field, d50 [mm]	100±15	80±15
10,Light field diameter adjustable [mm]	220-300	200-280
11,The way of adjustalbe light field diameter	Electrically	Electrically
12,Depth of illumination (L1 + L2) [cm]	110	130
13,Heat-to-light ratio [mW/m2-lx]	3.3	3.3
14,Temperature increase in head area Approx [°C]	≤2	≤2
15,Light sources [pcs]	111 high performance LED	72 high performance LED
16,Life time light sources [h]	50000	50000
17,Max. Power consumption of all light sources [W]	111	72
18,Power supply	24 V AC/DC, 100 V - 240 V AC	24 V AC/DC, 100 V - 240 V AC
19,Ceiling height for installation [cm]	270-320	270-320

PRODUCT ADVANTAGE

1.High quality with imported LED cold light source

2.High quality with titanium main arm

3.High quality with optional imported spring arm

Packaging & Shipping

Packaging Details:	5PLY Paper Shipping Carton / Wooden Shipping Carton package or OEM appointed packages.
Delivery Detail:	10-15 working days after we confirm the receipt of the deposit payment by T/T.

Our Services

1.Low MOQ: It can meet your promotional business very well.
2.OEM Accepted: We can produce any your design .
3.Good Service: We treat clients as friends.
4.Good Quality: We have strict quality control system .Good reputation in the market.
5.Fast & Cheap Delivery: We have big discount from forwarder (Long Contract).
