Original SLIX-S ICODE RFID Cards
13.56MHz RFID ISO15693
The ICODE SLIX-S IC is a dedicated chip for smart label applications with the need for a higher security level, larger memory and/or a product which takes care of the increasing demand for perfect customer privacy. This IC is the third generation of a product family of smart label ICs based on the ISO standards ISO/IEC 15693 and ISO/IEC 18000-3, prolonging a successful story in the field of vicinity identification systems.
The ICODE system offers the possibility of operating labels simultaneously in the field of the reader antenna (anti collision). It is designed for long range applications.
Features & Benefits
- ICODE SLIX-S RF interface (ISO/IEC 15693)
- Contactless transmission of data and supply energy (nobattery needed)
- Operating distance: up to 1.5 m (depending on antennageometry)
- Operating frequency: 13.56 MHz (ISM, world-wide licencefreely available)
- Fast data transfer: up to 53 kbit/s
- High data integrity: 16-bit CRC, framing
- True anticollision
- Electronic Article Surveillance (EAS)
- Application Family Identifier (AFI) supported
- Data Storage Format Identifier (DSFID)
- ENABLE PRIVACY command with 32-bit Privacy password
- DESTROY SLIX-S command with 32-bit Destroy password
- Additional fast anticollision read
- Write distance equal to read distance
- EEPROM
- 2048bits (2KB), organized in 64blocks of 4bytes each,4blocks are summed up to 1page
- 50 years data retention
- Write endurance of 100000 cycles
- Security
- Unique identifier for each device
- Lock mechanism for each user memory block (writeprotection)
- Lock mechanism for DSFID, AFI, EAS
- Password (32-bit) protected memory management for Read access
- Password (32-bit) protected memory management for Writeaccess
- Password (32-bit) protected Label Destroy
- Password (32-bit) protected Privacy Mode
- Password (32-bit) protected EAS and AFI functionality
Applications
- Libraries
- Item level tagging in pharmaceutical supply chains
- Counterfeit protection for consumer goods
- Industrial applications
- Asset and document tracking
Specifications
| Product Type | Contactless RFID Card |
| Material | PVC |
| Printing | Full color offset printing |
| Size | 85.6 * 54mm (thickness: 0.76mm, customizable) |
| IC Smart Chip | ICODE SLIX-S |
| Frequency | 13.56 MHz |
| Storage Capacity | 1024 bits |
| Heat Endurance | -5°C to 70°C |
| Function | can be read and written |
| Life Time | >10 Years |
| Surface Finishing | Glossy, Matte, Frosted Finish |
| Printing | Custom logo printing/CMYK printing / Silk-screen printing |
| Customer Options | Numbering, barcode, QR code, DataMatrix Code, Embossing, Magnetic Stripe, Signature Panel, Password Scratch-off Panel, Hot Stamping, Metallic Background, Transparent sticker and UVI, on metal / anti-metal feature |
| Applications | e-Payment, Membership Management, Access Control, NFC Applications and so on |
| Samples | Available |
| Shipping | Express, China Post, by air, by sea |
Smart IC cards and tags Showcase
Car, House, Tree shaped NFC Tags
