Help Center5MP 1" Format C Mount Manual Iris 20mm Fixed Focus Lens for Machine Vision
Related Products
-
5MP 1" Format C-mount Manual Iris 25mm Fixed Focus Lens for Machine VisionUS$ 1500.00 - 1800.00MOQ: 1 Piece -
5MP 1" Format C-mount Manual Iris 25mm Fixed Focus Lens for Machine VisionUS$ 2500.00 - 3500.00MOQ: 1 Piece
-
2MP 1/2" Format C-mount 2.0x Magnifying WD 40mm Telecentric LensUS$ 1500.00 - 1800.00MOQ: 1 Piece
-
10MP 1/2 Inch Format C-mount 0.8x Magnifying WD 65mm Telecentric LensUS$ 1600.00 - 1800.00MOQ: 1 Piece
-
10MP 1/2" Format C-mount 1x Maganifying WD 65mm Telecentric LensUS$ 1600.00 - 1800.00MOQ: 1 Piece
SPECIFICATIONS
| Resolution: | 150lp/mm(5MP ) |
| Format: | 1 |
| Mount : | C |
| Focal Length: | 20mm |
| F/No : | F2.0~ F22 |
| Back Focus : | 15.69mm |
| I ris Type : | Manual Iris |
| Angle of View: | 48° |
| Distortion : | <0.7% |
| Focusing Range: | ∞ ~ 0.3m |
| Filter Thread : | M37.5 x 0.5 |
| Dimension : | 40 x46.61mm |
| Weight : | 143g |
DIMENSIONS
1)Brilliant Technology is dedicated to being the leading provider of optical components and integrated optical inspection devices with high standard quality control. This goal will be achieved through our focus on the raw material selection, manufacturing process inspection, sampling,finalization and transportation monitoring.
2) During the manufacturing and sampling procedures, precious optical devices shall be used on the optical parameter detection such as surface irregularity, surface scratch,refractive index, coating and etc.
3) Not only optical components were strictly selected, but also the integrated devices. Every module will be under a series of spec run before releasing itself. Evaluation report comes along with the in-house test for the insurance of each devices’ regular working.
