Home > Light Industry & Daily Use > Exhibition and Advertising Equipment > Other Exhibition and Advertising Equipment > 15 Inch Digital Frameless Easy to Use and Install Advertising Lcd
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
OEM
Model Number:
AD1508F
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen/HK
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Retail Store Wall Mount 22 Inch Video Display Advertising PlayerNegotiableMOQ: 5 Pieces -
Flintstone Supermarket 7" Lcd Advertising ProductsNegotiableMOQ: 5 Pieces
-
Flintstone 15 Inch Cctv Lcd Display Monitor With Open Frame DesignNegotiableMOQ: 1 Piece
-
Flintstone Open Frame 15 Inch Security Lcd Display Monitor With Metal CaseNegotiableMOQ: 1 Piece
-
Flintstone 15-55 Inches Open Frame Design Surveillance Lcd DisplayNegotiableMOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
OEM
Model Number
AD1508F
Type
TFT
Application
Indoor
Panel Size
15 inch
Max Resolution
1024*768(H * V) P
Viewing Angle
70°/70°/60°/65°(L/R/U/D)
Contrast Ratio
400:1
Brightness
400cd/㎡
Input Voltage
DC4A, 48W (MAX)
Specifications
easy to use and install advertising lcdLong hour play and replay
USB easily updated function
CE, RoHs&FCC certificate
15 inch digital frameless easy to use and install advertising lcd
Key Function:
1. Open frame instruction design, which is flexible to embed into structure objects.
2. Upgrade contents of the memory card (or Built-in memory) by simply inserting an USB flash drive
3. The player starts automatically when the IR body sensor detects an approaching viewer (optional and external)
4. Timer function: the player turns on / off at the same time everyday according to your setting
Main Function:
1. Play mp4 advertising video, mp3 music and digital photos; Built-in 15 inch (4:3) TFT LCD screen; Flexible to embed into all kinds of structure objects.
2. Play from: --Compact flash card (CF card) --USB flash drive --Built-in memory
3. Upgrade contents of the memory card (or built-in memory) by simply inserting an USB flash drive, no need to take out of the memory card
4. Timer function: the player powers on / off automatically everyday at the time pre-set; It can also automatically play and non-stop replay within the pre-set time frame
5. No DVD style mechanical movement, hence more durable and suitable for long-hour advertising playing
6. Audio output (external): 2 X built-in high quality stereo speakers
| Model | AD1508F | |
| LCD Screen | LCD Size: | 15 Inch |
| Active Area: | 304.1 (W) * 228.2 (H) (mm) | |
| Screen Ratio: | 4:3 | |
| Resolution: | 1024 x 768 (H*V) | |
| Brightness: | 400cd/m2 | |
| Contrast Ratio: | 400:1 | |
| View Angle: | 70°/70°/60°/65°(L/R/U/D) | |
| Support Formats | Video: | MPEG1 (VCD), MPEG4 |
| Audio: | MP3, WMA | |
| Picture: | JPEG, BMP | |
| Picture optimum resolution | 1600*1200(H * V) P | |
| Video optimum resolution | 720*480(H * V) P | |
| Play From | Memory Flash: | CF card, Max. 8GB. SD card is optional before production |
| Built-in Flash Memory: | Optional, confirm before production | |
| USB: | High speed USB 2.0 OTG (Host) | |
| Installation | Embedding | |
| Others | IR body Sensor Distance: | Optional, 3m |
| Remote Controller Distance: | 4-5m | |
| Input Voltage: | AC100V-240V (50HZ-60HZ) | |
| Power Supply: | DC4A, 48W (MAX) | |
| Speaker: | Built-in 2x2W high quality stereo loudspeakers | |
| Working Temperature: | 0°C-45°C | |
| Storage Temperature: | -20°C-45°C | |
| Working Humidity: | 20%-80% | |
| Storage Humidity: | 10%-95% | |
| Casing: | Metal cold-rolled plate | |
| Body Size: | 355(L) * 260(W) * 35(H) (mm) | |
| Body Weight: | 3.2 (kg) | |
| Package | Standard Accessories | AC power adaptor, User's manual or CD disk, Remote control, Spare screws |
| Unit Size: | 45.5 * 14.5 * 35.5 (cm) | |
| Unit Weight: | 4 (kg) | |
| Carton Size: | (cm) | |
| Carton Weight: | (kg) | |
| Units Per Carton: | pcs | |
