Help CenterHigh Quality LNB Single ku Band
Related Products
-
2016 Best ku Band LNB Egypt MarketUS$ 0.5 - 0.9MOQ: 5000 Pieces -
LOW COST Universal LNB Single Mini SizeUS$ 0.5 - 0.9MOQ: 5000 Pieces
-
2016 Top Rated Universal ku Band LnbNegotiableMOQ: 5000 Pieces
-
2016 New Best Low Cost Universal Ku-band Twin LnbUS$ 1 - 2.3MOQ: 1000 Pieces
-
Best Quality Factory Price Digital Universal Ku-band Single Lnb for Europe Market/high Gain and Low Noise Figure Single LnbfUS$ 0.1 - 1.5MOQ: 2000 Pieces
Low noise figure
Digital ready
Low power consumption
Easy installation
High quality weather protection
Superior Phase Noise performance, DVB-S2 (HDTV) compliant
Higher Conversion Gain
Excellent Cross Polarization Isolation
Ultimate Reliability
-
Item Specification Item Specification Input Frequency Range Low Band:10.70~11.70GHz Gain Flatness ±0.5dB/26MHz High Band:11.70~12.75GHz Cross POL. Isolation 25dB(Typ.) Output Frequency Range Low Band:950~1950MHz Image Rejection 40dB(Min.) High Band:1100~2150MHz Output VSWR 2.0:1(Max.) L.O. Frequency Low Band:9.75GHz P1dB 0dBm (Min.) High Band:10.60GHz DC Current Consumption 80mA(Typ.) L.O. Frequency Stability ±1.0MHz (Max.)@+25℃ Low/High Band Switching Low Band:0Hz ±2.0 MHz (Max.)@-30℃~+70℃ High Band:22KHz±4KHz L.O. Phase Noise -60dBc/Hz@1KHz POL. Switching Voltage 10.5~14.0V @Vertical -80dBc/Hz@10KHz 16.0~20.0V @Horizontal -100dBc/Hz@100KHz Relative Humidity 0%~95% Conversion Gain 60dB(Typ.) Operating Temperature -30℃~+70℃ Noise Figure 0.3dB(Typ.) Connector Type 75Ω Female Connector
OFFER [OEM box] [white box]
100pcs/ctn
canton box size: 48.7*34*34.5 cm
Gift box: 64*64*118 mm
If you have any questions, please feel free to email to us. 24 Hours a Day, 7 Days a Week, and we will reply you ASAP. If no response within 24 Hours, please check the spam of mail box or kindly re-send it to us.
1.Where has this product been sold?
Cover seven continents,224 countries in the world.
2. What certification does the products have?
CE,GMC
3.What kind of package can you offer?
OEM box with your brand, white box, gift box
