product name: New arrival Universal Twin KU-band LNB
Full coverage of Ku-Band for Analog and Digital reception
Low noise figure
Easy installation
Low power consumption
High quality weather protection
-
Item Specification Item Specification Input Frequency Range Low Band:10.70~11.70GHz Gain Flatness ±0.5dB/26MHz High Band:11.70~12.75GHz Cross POL. Isolation 25dB(Typ.) Output Frequency Range Low Band:950~1950MHz Image Rejection 40dB(Min.) High Band:1100~2150MHz Output VSWR 2.0:1(Max.) L.O. Frequency Low Band:9.75GHz P1dB 0dBm (Min.) High Band:10.60GHz DC Current Consumption 80mA(Typ.) L.O. Frequency Stability ±1.0MHz (Max.)@+25℃ Low/High Band Switching Low Band:0Hz ±2.0 MHz (Max.)@-30℃~+70℃ High Band:22KHz±4KHz L.O. Phase Noise -60dBc/Hz@1KHz POL. Switching Voltage 10.5~14.0V @Vertical -80dBc/Hz@10KHz 16.0~20.0V @Horizontal -100dBc/Hz@100KHz Relative Humidity 0%~95% Conversion Gain 60dB(Typ.) Operating Temperature -30℃~+70℃ Noise Figure 0.3dB(Typ.) Connector Type 75Ω Female Connector
OFFER [OEM box] [white box] [gift box]
50pcs/ctn
canton box size:56*34.5*30 cm
Gift box size: 108*65*137mm
1.Where has this product been sold?
Cover seven continents,224 countries in the world.
2. What certification does the products have?
CE,GMC
3.What kind of package can you offer?
OEM box with your brand, white box, gift box
