Specifications
bio filter media for wastewater1.150g/m2,
2. washable 2-3 times,it's strong and not easy to split.
bio filter media for wastewater
1.150g/m2,
2. washable 2-3 times,it's strong and not easy to split.
This series mainly absorbs the larger particles to prevent the early ceiling filter block, it is made from hardened fiber and is covered with glue for hardening and stabilizing the fiber, the hardness and density are better than the same kinds of products, the primary filtration efficiency and the air flow rate have been increased.
Hardened primary filter(blue & white)
This series is made of prolonged and hardened fiber, it is sprayed with special blue glue. The blue glue is able to show the use life directly, when the blue part being covered with dust totally, the filter must be replaced.
Model | AF-200G | AF-150G |
Weight: | 200gr/sqm | 150gr/sqm |
Thickness: | 15mm | 13mm |
Air Flow Rate: | 1980m3/h | 2160m3/h |
Initial Resistance: | 15pa | 15pa |
Final Resistance: | 200pa | 200pa |
Medium Arrestance: | 77.40% | 68.30% |
Air Velocity: | 0.55m/s | 0.60m/s |
Dust Holding: | 285gr/sqm | 254gr/sqm |
Max Temperature: | 1100C | 1100C |
Filtration Class: | G3(DIN 24185) | G2(DIN 24185) |
Flame Resistance: | F-1(DIN 53438) | F-1(DIN 53438) |
Primary filter(white)
AZ series mainly absorbs the larger particles to prevent the early ceiling filter block, it is made from hardened fiber and is covered with glue for hardening and stabilizing the fiber, the hardness and density are better than the same kinds of products, the primary filtration efficiency and the air flow rate have been increased.
Model | AZ-300G | AZ-200G | AZ-150G |
Weight: | 300gr/sqm | 200gr/sqm | 150gr/sqm |
Thickness: | 18mm | 15mm | 12mm |
Air Flow Rate: | 1620m3/h | 2050m3/h | 2160m3/h |
Initial Resistance: | 16pa | 15pa | 15pa |
Final Resistance: | 200pa | 200pa | 200pa |
Medium Arrestance: | 82.50% | 75.40% | 66.40% |
Air Velocity: | 0.45m/s | 0.50m/s | 0.60m/s |
Dust Holding: | 325gr/sqm | 269gr/sqm | 246gr/sqm |
Max Temperature: | 1100C | 1100C | 1100C |
Filtration Class: | G4(DIN 24185) | G3(DIN 24185) | G2(DIN 24185) |
Flame Resistance: | F-1(DIN 53438) | F-1(DIN 53438) | F-1(DIN 53438) |
