air bag filter with GI frame
·Large air flow
·Low resistance.
·Washable
·Large dust holding capacity
·Low operating cost
Type: multi-pocket design
Frame: aluminum,extruded galvanized or plastic frame
Media: Polyester/Synthetic fiber
Efficiency: 35%
Standard:EN779 G1~G4
DIN53438 Non-flammability Standard: F1
Final resistance: (suggested)250Pa-350Pa
Max. air flow: 125% of the rated air flow
Temp. resistance: ≤70℃
Humidity: 90%
Applications:
Used in commercial and industrial ventilation and air conditioning systems,the automobile industry,hotels and office buildings.
Technica Parameters:
W×H×D |
Pockets |
area |
Efficiency |
Airflow(CMH) |
Initial Pressure |
Airflow(CMH) |
Initial Pressure |
(mm) |
(m2) |
(CMH) |
(Pa) |
(CMH) |
(Pa) |
||
591×592×380 |
6 |
3.29 |
G3 |
2540 |
30 |
3800 |
45 |
G4 |
45 |
65 |
|||||
487×591×380 |
5 |
2.73 |
G3 |
2100 |
30 |
3150 |
45 |
G4 |
45 |
65 |
|||||
487×591×380 |
5 |
2.31 |
G3 |
1720 |
30 |
2580 |
45 |
G4 |
45 |
65 |
|||||
286×591×380 |
3 |
1.63 |
G3 |
1240 |
30 |
1860 |
45 |
G4 |
45 |
65 |
Recommended final pressure: 250Pa
Pressure range:±15%
Remark:Different sizes and specifications are available.
