Stainless steel electrical heating/steam heating chemical reaction reactor heating jacket reactor
1. Operating principle: Break down or recombined the materials through mixing, filling and cooling, to promote the reaction of polymerization.
2. Components: Body, gears, mixing devices, heating devices, cooling devices, seal, etc.
3. Auxiliary Equipment: Distillation column, head tank, condenser, water separator, collecting cans, filters, etc..
4. Widely used in: Resins, adhesives, paint, cosmetics, pharmaceutical and other chemical production.
5. Applicable Field: All the liquid-liquid, liquid-powder reaction industry.
2. Instruction:
1).Reactor kettle is the main chemical react production equipment, which is widely used in resins, adhesives, paint, cosmetics, pharmaceutical and other chemical production.
2).Break down or Re-combined the molecule through mixing, Heating, cooling, Vacuumize, etc. Suit for polymerization, hydrogenation, vulcanization, nitration,etc. The reactor is made up of body vessel, jacket vessel, gears, mixing devices, heating devices, cooling devices, seal composition,etc. The auxiliary equipment:Head tank, distillation column, condenser, water separator, collecting cans, dilution tank, filters ect.
3. Model selection reference of reaction kettle
Composition |
Instructions |
Specification (L) |
50-50000 |
Design Pressure (Mpa) |
Atmospheric Pressure or under pressure |
Material |
Carbon steel, stainless steel, enamel, graphite |
Heating Forms |
Electrical heating with medium in jacket, external half coil steam heating, external half conduction oil heating, hot water infrared heating etc. |
Cooling Forms |
Refrigeration medium in the internal pipe jacket |
Blending Power |
Model selection is made according to material viscosity, liquid-solid ratio, liquid specific gravity, solid specific gravity, solid granularity, rotation speed, paddle type, with or without baffle or internal coil. |
Stirring blade Forms |
Anchor type, frame type, flat paddle type, pitched paddle type, ribbon type, turbo type, pusher type and multiple compound type |
Seal |
Mechanical seal or stuff packing seal |
Inner Surface Treatment |
Polished or no polished |
Discharge Valve |
Flanged ball valve, open downward discharge valve and others |
Technological Pipe Hole |
Manhole, sight glass, distillation mouth, imported materials, pressure gauge port, temperature, mouth, mouth filling N2, |
