Home > Packaging & Printing > Packing Machinery > Sealing Machine > Tube Filling And Sealing Machine With Tube Feeding System

Tube Filling And Sealing Machine With Tube Feeding System

Name: Tube Filling And Sealing Machine With Tube Feeding System
Brand: shsina
SKU: 108475861
Availability: InStock

Tube Filling And Sealing Machine With Tube Feeding System thumbnail-1

Tube Filling And Sealing Machine With Tube Feeding System thumbnail-2

Tube Filling And Sealing Machine With Tube Feeding System photo-1

Tube Filling And Sealing Machine With Tube Feeding System photo-2

US$ 8,000 - 29,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Application:

Chemical, Food, Other, Chemical, Food, Plastic Tube,Laminated Tube

Packaging Type:

Other, Tube

Contact Supplier Request Quote Chat Now

Shanghai Sina Light Industry Mechanical Device Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Application Chemical, Food, Other, Chemical, Food, Plastic Tube,Laminated Tube

Packaging Type Other, Tube

Packaging Material Plastic

Automatic Grade Automatic

Driven Type Pneumatic

Voltage 220V/380V

Power 1.2KW

Place of Origin Shanghai, China

Brand Name shsina

Model Number SXL-60

Dimension(L*W*H) 1650*1400*1980mm

Weight 800KG

Certification CE Certification

After-sales Service Provided Engineers available to service machinery overseas

Tube Filling and Sealing Machine

SXL-60 Full Automatic Tube Filling and Sealing Machine

This machine is a high-tech product which successfully developed and designed by adopting advanced technology from abroad and strictly meet GMP requirement. PLC controller and color touch screen are applied and made it possible for programmable control of the machine. It can perform the filling for ointment, cream jellies or viscosity material, sealing or tail folding, batch number embossing (include manufacture date) automatically. It’s ideal equipment for plumbum tube, plastic tube and laminated tube filling and sealing for cosmetic, pharmacy, foodstuff and bond industries.

Features

With 9 stations and matching with manipulator, the machine is able to meet different type of tail folding, sealing requirements of plumbum tube, Alu tube, plastic tube and laminated tubes. It is a multi-purpose machine.
Tube feeding, eye marking, tube interior cleaning (optional), material filling, sealing (tail folding), batch number printing, finished products discharging can be performed automatically (the whole procedure).
Servo control makes it precise and convenient to adjust the filling amount by touch screen.
According to the different length of the tube, height of tube chamber can be adjusted easily by motor. With external reversal feeding system, makes tube charging more convenient and tidy.
The mechanical linkage photo sensor precision tolerance is less than 0.2mm. The chromatic aberration scope between tube and eye mark is reduced.
Photo-electronic, electric, pneumatic integrative control is applied with the machine. No tube, no filling. It gives an alarm when low pressure occurs. The machine stops automatically if tube error or open the safety door.
Three-layer jacket instant heater with inside air heating, it won’t damage the pattern on outer wall of tube and achieves firm and beautiful sealing effect.

Main Technical Pharameters

Model	SXL-60
Tube Material	Plastic tube, Laminated tube,Aluminum Composite Tube
Tube Diameter	Φ10mm-Φ50mm
Tube Length	30-250mm (customizable)
Filling Volume	10-250ml/piece (Adjustable)
Filling Accuracy	≤±1%
Product Capacity (Pcs/min)	30-60pcs/min
Air Supply	0.55-0.65Mpa
Motor Power	4kw (380V/220V 50Hz)
Heat Sealing Power	5kw
Overall Dimension(mm)	280712401900mm (LWH)
Machine Weight (kg)	1100kg

Application:

Food Inustry: Tomato Suace,Salad Dressing,Mayonnaise,Cheese,Jam,Fruit Sauces,BBQ Sauces,Peanut Butter,Oil,Pectin,Jelly,Honey,Juice,Milk,alginate etc.

Cosmetic Industry: Facial Cream, BB Cream, Hand Cream, Toothpaste, Detergent, Shampoo, Lotion, Perfume, Gel, Hair Conditioner, Powder, Powder, Liquid Products etc.

Chemical Industry: Grapheme, Paint,Pesticide,Lubricant,Cleanser, Wax,Aluminum Dioxide etc.

Pharmacy Industry: Ointment, Gel, Eye drops, Cough Syrup, Suppository, Cephalosporin Suspension, etc.
