Automatic food can lableing machine SXL-650A machinery
Product Description
1. The Scope of Application
Label differnet size round objects in food, medicine, daily chemical and other light industries.
2. Equipment composition
Electrical cabinet,Conveying mechanism,Separate bottle device,Roll label device,Brush label device,1# labeling engine,Operation system and control system ;
3. Equipment function characteristics
l Control system: Use SIEMENS brand PLC control system, with high stable operation and extremely low failure rate.
Operation system:The man machine control 7 inch touch screen, directly visual interface easy operation, with Chinese and English two kinds language, also rich withthe help function and fault display function.
l Send label system: Use SIEMENS high-power servo control system, stable with high speed.
l Parameter save:can save 10 groups labeling parameters, when change bottles don’t need reset parameters, just adjust machine part is ok.
Alarm function: Such as label spill, label broken or other malfunction during machine working all will alarm and stop working.
Machine Material: Machine and spare parts all use material S304 stainless steel and anodized senior aluminum alloy,with high corrosion resistance and never rust.
Labeling way : Use the servo send label system to send label on product surface.
Low voltage circuit all use the German Schneider brand.
4.Technical Parameter
Model |
SXL-650A |
Operating direction |
Left or Right |
Labeling Accuracy |
±1.0 mm(subject to the roughness of the plane) |
Production(bottle/min) |
60-200(according to the size of bottle and label) |
Labeling Speed(m/min) |
≤40 |
Label Specifications |
adhesive stikcer label,transparent or opaque |
The application of bottle |
Outer diameter 15-50mm Height 35-100mm |
The application of label |
Height 10-80mm ; Length 23-100mm |
The inner diameter of label roll |
76mm |
The outer diameter of label roll |
350mm (max) |
The power of motor(w) |
550W |
Voltage |
AC220V 50/60HZ Single phase |
Size appearance(mm) |
1800(L) 700(W) 1270(H)mm |
