Help CenterSINA High Quality Shampoo Filling Machine
Related Products
-
Adjustable Speed Vertical Semi-automatic Cream Filling MachineUS$ 500 - 2,000MOQ: 10 Sets -
Hot Sale Automatic SGJ Full Automatic Filling MachineUS$ 5,000 - 30,000MOQ: 1 Set
-
Aseptic Manual Filling MachineUS$ 500 - 1,000MOQ: 10 Sets
-
Pneumatic Cosmetic Filling Machine (horizontal)US$ 800 - 1,500MOQ: 6 Sets
-
2016 Sina Hot Sale Full Automatic Shampoo, Body Lotion, Cream Filling Machine Quality ChoiceUS$ 9,000 - 25,000MOQ: 1 Set
4 heads Quality Guaranteed Automatic Stainless Steel Shampoo Filling Machine
Specifications, function and feature | ||
1 |
apply to |
medicine, pesticides, food, cream, paste, liquid soap, commodity, cosmetics, chemical and so on |
2 |
materials required |
viscosity and hardness of materials ≤30000cps |
3 |
Filing volume range |
100-1050ml, Maximum volume: 2500ml, can adjustable according to customer needs. |
4 |
Material |
material contact parts:SS316 or SS304 |
5 |
Control |
Variable speed control, according to the different viscosity filling material filling rate adjustment, It can be independently to control each filling nozzle. |
6 |
Anti-drip filling nozzle |
Angle seat valve, preventing leakage and wire drawing. |
7 |
cylinder |
AIRTAC, JELPC, made in China or import. It according to customer needs. |
8 |
Safety |
optical and ultrasonic testing of materials and bottle, no bottle, no filling features missing bottle, filling bottle counting function, PLC control, touch screen operation. |
9 |
Discharge material of control |
the implementation of power sector for the SS316 material pneumatic shuttle valve, filling the mouth for the SS316 angle seat valve, |
10 |
Adapt the size of bottle |
bottle height (150 ~ 260mm) |
11 |
Feed material of the control |
stainless steel material of the storage container which put on the top of the filing machine, it also can connect to the feeding pump for feeding material.( the pump price other calculate) |
12 |
Control the bottles |
Bottle clip fixtures (horizontal pneumatic double folder), to avoid dislocation filling. |
13 |
Power |
220V, 50HZ, 0.5 KW. (different country different power, it can add inventor, the price other calculate) |
Technical parameter
Filling range |
100-1000ml( it according to customer needs) |
Filling speed |
10-90 bottles/ min(500ml) |
Air consumption |
1000L/minute |
Rated power |
0.8 KW |
Working power |
220V |
Filling heads |
2-24(it according to customer needs) |
overall dimensions |
2000*1200*2100 (mm) |
Weight |
600kg |
