AC drive electric order picker THA
Description:
High Level Order Picker(MIMA brand)
1. The cover board with direction display, easy to know the driving direction even in high-order position;
2. The Vehicle have driving alram,and safety belt, to ensure the safe driving;
3. Mast Buffering function;
4. The high level order picker including automatic high level order picker and semi-automatic high level order picker;
5. THA Series High level order picker, rated load capacity: 1000kg, max lift height:4500mm
6. With driving direction display, easy to know the direction even in high level;
7. With driving alarm and safety belt;
8. Mast with buffering function.
9. it has free lift (lift height 700mm)
Descriptiom |
THA10A30 |
Operation Type |
Stand-on |
Rated Load Capacity (KG) |
1000 |
Load center MM |
450 |
Max Lift Height (mm)--H |
3000 |
Min. Road Clearance- Fork(mm)--H |
30 |
Max./Min.Height-Operation Compartment (mm)--H1 |
3233/243 |
Max./Min.Height-Overhead Guard (mm)--H2 |
5237/2250 |
Height-Mast Lowered (mm)-H3 |
2250 |
Height-Mast Extended (mm)-H4 |
5237 |
Overall Length (mm)--L |
2734 |
Front tread (mm)--L1 |
942 |
Rear tread (mm)--L2 |
702 |
Length-Fork (mm)-L3 |
1802 |
|
Overall Width (mm)—W
|
1080
|
Working platform size mm |
600*600 |
Fork Width-Outer (mm)--W2 |
700 |
Min Turning Radius (mm)-Ra |
1640 |
Wheel Type |
PU |
Wheel Size-Drive (mm) |
230*70 |
Rear Wheel(mm) |
150*90 |
Banalce Wheel-(mm) |
150*50 |
Travel Speed-Laden/Unladen-(km/h) |
4/4.8 |
Lift Speed-Unladen-(mm/s) |
110/125 |
Gradeability-Laden/Unladen-% |
/ |
Driving Motor (KW) |
AC1.1 |
Lifting Motor (KW) |
3 |
Steering Motor (KW) |
0.75DC |
Battery-V/AH |
24/480 |
Charger V/A |
24/70 |
Service Weight (with battery) KG |
2600 |
