reci tube used in laser equipment with long life time and high stability
- 100 Set / Sets per Month
- Qindao or Shanghai
- T/T L/C D/P D/A Credit Card PayPal
- 150w laser tube used in laser equipment with long life time and high stability
- 130w laser tube used in laser equipment with long life time and high stability
- laser tube used in laser equipment with long life time and high stability
- laser tube used in laser equipment with long life time and high stability
- Raycus or IPG 10w 20w 30w 50w laser machine
- Raycus or IPG 10w 20w 30w 50w 20w optical fiber machine
Product Details
Laser Type: | CO2 | Applicable Material: | Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood | Certification: | CE, ISO, GS, SGS, UL, CCC |
Place of Origin: | Shandong, China | Brand Name: | Reci | Model Number: | W6 |
Packaging Details
within a plywooden box
Product Description
Specifications
reci tube1.CE,FDA and other international certification
2.10000 hours longtime
3.guarantee:10 monthes
4.Brand:Reci
reci tube
1.reci tube pictures |
2. Installation Requirement of reci tube |
Make sure to follow the operation instructions of model W2 as shown in the illustration. The dedicated power DY10 should be equipped. The positive pole is in high voltage (the ignition voltage is 19kv). It may cause the following consequence when it is failed to follow the instruction: Arcing; the inner tube will be punctured by electricity and may cause water leakage. |
3. Operation conditions of reci tube |
1)Water cooling: using purified water; 2 to 5 liter/minute; water temperature: 10°C-40°C. 2) The operating environment: temperature 2-40°C, humidity 10-60%. 3) The working current: test current is 29mA. Maximum working current is 29mA. The running current must be kept below 27mA. The life span can reach 10,000 hours if the current is kept below 25mA. The ammeter indicating current must be connected to the negative electrode of the laser tube. 4)When it is working under over-high current for long term, the negative pole will appear light yellow, and the life span will be reduced rapidly. 5)To protect dust from going into the insulation sheath, please wrap it with plastic film. |
4. Working Performance of reci tube |
1) Cutting function. 2)Engraving function: Very good, when the working current is 4mA and the tube is in the state of preionization, the laser can be used for high-frequency impulse engra |
5. Key Notes of reci tube |
Do not clean the exterior surface of the output widow mirror with tools such as tampon; otherwise the output power will be seriously affected. The followings are the designated methods to clean up pollution in the exterior surface of window mirror: 1) When the mirror is polluted, do not turn on the laser. 2) Blow the mirror surface sideway with air blower. 3) Spray the pure alcohol on the mirror surface with sprayer. 4) Turn on the laser after the alcohol gets fully volatilized. 5) If the methods above don't work effectively, it is necessary to ask for the professional to use tampon with alcohol to clean the mirror surface from middle to edge. The best solution is to prevent the window from being polluted.
Attention: it is forbidden to clean the mirror with acetone The screw in the front and back ends of the laser tube is not allowed to be moved, otherwise the out power will be declined and even the tube may be scrapped.
Put the acryl 300mm far away from output mirror, when testing the laser spot. |
6. Safety of reci tube |
The laser beam is invisible light. Please wear protective glasses when debugging the laser. The positive pole is in high voltage. Pay attention to the security marks. |
7. Storage and Transportation Requirement of reci tube |
Pour out cooling fluid in the event of storage and transportation, and cover the output terminal with a dust-proof plastic bag. The storage environment is 2-40°C, and the requested humidity is 10-60%. Pack the laser as in the original way.
Important notes: it is requested to cement the sponge together with laser tube to prevent the tube vertically sliding during transportation. The sponge in the side of output mirror must be 70mm beyond it, and the sponge in the side of reflecting mirror must be 50mm wider.
|
9. Application of reci tube in Dowell Laser equipment |
|
10.Warranty of reci tube |
|
11.Contact person of Dowell |
Contact:Jinan Dowell Photoelectricity Equipment Co.,Ltd Address:Xinxu industrial park,North Er'huan Road,Tianqiao District,Jinan city,China Contact person:April Skype:Aprillyx |
Company Profile
Jinan Dowell Laser Equipment Co.,ltd. (the former Wuhan Dowell Laser), with 12 years production experience, specialized in laser cutting, marking equipment production, developing and sales, and procide customers with comprehensive solutions, compare to same industry, we hold less autonomy R& D companies. Company's full range of products have passed CE, FDA and others international certification.
Since established of our company, now there are more than 130 technicist and 20 research personnels after continuous improvement of management. Our company occupy 3000 square meters of modern workshops, located in the Xinxu Industrial Zone of Tianqiao District, Jinan City with traffic convenient. We have established more than 20 agencies all over China, such as Guangzhou, Shanghai, Beijing, Zhejiang, Fujian, etc. We have established agent relations covering 30 countries and areas. Our products are exported to more than 60 countries and areas all over the world, including America, Russia, Germany, Turkey, Southeast Asia etc.
We have the first class total production line, formed all types and functions of the product structure. In the cultroat market competition, we absorbed fully advanced ideas in the international field. We have independent researched a series of laser engraving machine and cutting products. The series of DOWELL products inject the newest design concept with integration of laser, engine and electricity. So that in the performance the precision and appearance reached the perfect combination, meet the different level demands of users. High quality is our pursuit ,we adopt original importing components, Advanced manufacturing technology, large mass production and high standard testing. Perfect comprehensive after-sale service, won the customers support and trust. Customer first credit first is our highest conviction,through our persistent effort ,we believe,we will build a brilliant future with you!
