Help CenterDW 2225 Large Materials Laser Cutting Bed
Related Products
Applicable industries
Plastic and rubber industry, ads/crafts/presents industry.strument/machine componnents,leather cloth industry. Advertising logo signs, gifts, crystal ornaments, paper cutting techniques, relief, wood carving Jane. Printing plate, leather clothing, embroidery, decoration, frame making and other industries.
1.Full up grading to operation offline and to support USB flash disc output. Rich function can effectivelly engrave on flat surface, gradient engraving by 360 degree.
2.Extensive material processing, smooth cutting edge and burr-free, avoid polishing. Optional double laser heads cutting machine to enlarge the efficiency.
3.It is integrates engraving, image scanning, grade carve, cutting etc.
4.With imported USA RF metal laser tube which is characterized by excellent beam quality, stable performance and long lifetime.
5.With imported gilded lens with silicon base and two-layer focusing system, the beam is sharper and cutting force is stronger.
6.The X.Y axis adopt imported linear guide rail and imported servo motor with speed-reducing driving system to make cutting stable and cutting surface smooth.
Laser Generator | Hermetic and detached CO2 laser tube |
Laser Power | 60w /80w /100w/150w/180w |
Work area | 2200*2500mm |
Positioning Precision | ±0.01mm |
Cooling Mode | Circulating-water-cooling |
Machine Control and Drive | Speedy DSP controlling, stepper motor |
Power Adjustment | 0-100% controlling, no segment and adjusting by software |
Controlling Software Language | English, Simplified Chinese, Traditional Chinese and procuring of multi-languages |
Machine Color | grey/Red , Orange/Grey |
Minimum Character | Chinese character 1.5mm, crisscross-row 1mm |
Max Power | ≤1500w |
Up-down Range of Working Table | 50mm |
Optional Equipment | Rotary attachment |
Engraving Speed | 1200mm/s |
Cutting Speed | 600mm/s |
Laser energy control | 1-100% software setting |
Interface | LCD Screen and USB interface |
Working Voltage | AC220V ±10%,50Hz |
Running Environment | 0-45°, Humidity: 5%-95% |
...
