Addressable WS2812b 5volt Magic Led Strip 5m

Addressable WS2812b 5volt Magic Led Strip 5m thumbnail-1
Addressable WS2812b 5volt Magic Led Strip 5m photo-1
US$ 5.5 - 6.9 MOQ: 50 Meters
Key Specifications
Get Latest Price
LED Light Source:
SMD5050
Type:
Flex LED Strips
Input Voltage(V):
5
Contact Supplier Request Quote Chat Now
Shenzhen Kingtar Technology Co., Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source SMD5050
Type Flex LED Strips
Input Voltage(V) 5
Lamp Power 7.2
Working Temperature(℃) -20, 60
Working Lifetime(Hour) 50000
Lamp Body Material Copper
Certification CE
Emitting Color Changeable
Place of Origin Guangdong, China
Brand Name Kingtar
Model Number KT-DT30-2812

Addressable WS2812b 5volt magic led strip 5m

Features and specifications

  • Individually addressable RGB LEDs (30,60 or 144 LEDs per meter)
  • 24-bit color control (8-bit PWM per channel); 16.8 million colors per pixel
  • One-wire digital control interface
  • 5 V operating voltage
  • Each RGB LED draws approximately 50 mA at 5 V with red, green, and blue at full brightness
  • 10 mm width, 4 mm thickness
  • Flexible, waterproof silicone rubber sheath (IP65 protection rating)/IP33 non-waterproof
  • Includes five flexible silicone mounting brackets per meter of LED strip
  • Black/white strip color
  • Power/data connectors on both strip ends for easy chaining, and the input side includes an additional power and ground wire for alternate power connections
  • Strips can be cut apart along the lines between each RGB LED segment to separate them into usable shorter sections
  • Example code available for Arduino, AVR, and mbed

Using the LED strip

Each LED strip has three connection points: the input connector, the auxiliary power wires, and the output connector. These can be seen in the adjacent picture, from left to right: auxiliary power wires, input connector, output connector. The strip uses 3-pin JST SM connectors.

The output connector is on the other end of the strip and is designed to mate with the input connector of another LED strip to allow LED strips to be chained.

APPLICATIONS:

1.Light source for LED Display,window display.

It can show any color,letters,animations,work same as LED Screen.

2.Hotel,supermarket,shopt decorations

3.Night club,DJ events lighting decorations

4.Gift kit for students,home decorations.

Addressable WS2812b 5volt magic led strip 5mAddressable WS2812b 5volt magic led strip 5mAddressable WS2812b 5volt magic led strip 5m
