Specifications
Refractory Motar Fire Clay Bricks1.clay brick
2.Brand Name:Leiyuan
3.Material:Clay
4.Certification:ISO9001,Type: Clay Brick
Glass Furnace Bottom Fire Clay Block Types of Refractory Bricks
Castable Refractory Recommendation for Cement Kiln 2000T/D~3000T/D
Application Parts |
Recommended products |
Application Parts |
Recommended products |
Rotary kiln front end |
LH-85A |
Hot end of grate cooler |
|
Rotary kiln back end |
LH-16K |
Other parts of grate cooler |
LH-75 |
Coal burner tube |
LH-80P |
Rising gas duct |
LH-50C |
Calciner |
LH-75 |
Kiln hood |
LH-75F |
Preheater |
LH-14N |
Tertiary air duct, parapet |
LH-80G |
3000T/D~5000T/D
Application Parts |
Recommended products |
Application Parts |
Recommended products |
Rotary kiln front end |
LH-85A |
Hot end of grate cooler |
LH-80G |
Rotary kiln back end |
LH-85G |
Other parts of grate cooler |
LH-16K |
Coal burner tube |
LH-85P |
Rising gas duct |
LH-50C |
Calciner |
LH-75F |
Kiln hood |
LH-75F |
Preheater |
LH-13NL LH-14N |
Tertiary air duct, parapet |
LH-80G |
Kiln end, grate cooler |
LH-80G |
|
|
5000T/D~10000T/D
Application Parts |
Recommended products |
Application Parts |
Recommended products |
Rotary kiln front end |
LH-85A |
Hot end of grate cooler |
LH-85 |
Rotary kiln back end |
LH-85 |
Other parts of grate cooler |
LH-16K |
Coal burner tube |
LH-85P |
Rising gas duct |
LH-55C |
Calciner |
LH-80 |
Kiln hood |
LH-80 |
Preheater |
LH-14N |
Tertiary air duct, parapet |
LH-80G |
Fire clay brick Standard sizing: 230 x 114 x 65 mm others up to the client
Fire clay brick SK-32 |
|
Item |
Standard |
AI2O3(%) |
30 |
Fe2O3 (%) |
3 |
Refractoriness (SK) |
32 |
Refractoriness under load, 0.2MPa, Ta, ((°C) |
1300 |
Porosity (%) |
22-26 |
Bulk density (g/cm³) |
2.05 |
Cold crushing strength (MPa) |
25 |
Thermal expansion at 1000°C (%) |
0.6 |
Fire clay brick SK-34 |
|
Item |
Standard |
AI2O3(%) |
38 |
Fe2O3 (%) |
2.5 |
Refractoriness (SK) |
34 |
Refractoriness under load, 0.2MPa, Ta, ((°C) |
1350 |
Porosity (% |
19-23 |
Bulk density (g/cm³) |
2.10-2.15 |
Cold crushing strength (MPa) |
25 |
Thermal expansion at 1000°C (%) |
0.6 |
Fire clay brick SK-36 |
|
Item |
Standard |
AI2O3(%) |
50 |
Fe2O3 (%) |
2 |
Refractoriness (SK) |
36 |
Refractoriness under load, 0.2MPa, Ta, ((°C) |
1450 |
Porosity (% |
20-24 |
Bulk density (g/cm³) |
2.30-2.40 |
Cold crushing strength (MPa) |
45 |
Thermal expansion at 1000°C (%) |
0.3 |
sk32 sk34 sk36 sk38 refractory fire clay brick for oven tunnel kiln firing kilns
